NZ 100
A
F
A
S
UTOMATIC
IRE
LARM
YSTEM
O
M
PERATORS
ANUAL
Document No ........................................................................G0097WO1
Issue No..................................................................................................1
Serial No ...................................................................................................
Issue Date .............................................................19th December 1996
Software Version ................................................................................1.0
AMPAC TECHNOLOGIES LTD PTY
UNIT D, 33 PORANA ROAD
GLENFIELD
AUCKLAND
NEW ZEALAND
PH : 64-9-443 8072
FAX : 64-9-443 8073
NOTE: INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT
NOTICE.
UNCONTROLLED DOCUMENT
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ampac NZ 100
Summary of Contents for Ampac NZ 100
- Page 1 PERATORS ANUAL Document No ................G0097WO1 Issue No....................1 Serial No ....................Issue Date .............19th December 1996 Software Version ................1.0 AMPAC TECHNOLOGIES LTD PTY UNIT D, 33 PORANA ROAD GLENFIELD AUCKLAND NEW ZEALAND PH : 64-9-443 8072 FAX : 64-9-443 8073 NOTE: INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
-
Page 2: Table Of Contents
AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL CONTENTS PAGE NO. 1.0 INTRODUCTION ..........................3 1.1 UNPACKING AND INSPECTION....................3 1.2 ANTI STATIC PRECAUTIONS......................3 2.0 SPECIFICATIONS ..........................4 2.1 POWER SUPPLY/BATTERY CHARGER ..................4 2.2 OUTPUTS............................4 2.3 DETECTOR CIRCUIT ........................4 3.0 SYSTEM DESCRIPTION........................5 3.1 GENERAL DESCRIPTION ......................5 3.2 FRONT PANEL LAYOUT ........................5... -
Page 3: Introduction
AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL INTRODUCTION UNPACKING AND INSPECTION Carefully check packing before unpacking goods for any transit damage. Unpack the goods and check both externally and internally for any loose or damaged components that may affect the appearance, installation or operation of the goods. -
Page 4: Specifications
AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL SPECIFICATIONS Size 220H x 290W x 80D POWER SUPPLY/BATTERY CHARGER Mains Supply 230V AC " 10% @ 0.5A Charger Output Voltage 13.5V DC Output Current 0.5A Battery (one of only) 12V 7AH System Quiescent Current... -
Page 5: System Description
AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL SYSTEM DESCRIPTION GENERAL DESCRIPTION The NZ100 is an automatic fire alarm system. The NZ100 has one fire detection circuit able to accommodate heat detectors, smoke detectors, manual call points or a combination of these devices. -
Page 6: Internal Layout
AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL INTERNAL LAYOUT Walk test switch Buzzer mute switch Reset switch Mains Termination and Fuse Mains Transformer WALK TEST BUZZER Battery MUTE RESET D.H. 250mA Door Holder fuse NORMAL BELL BELL Bell fuse BELL SYS. -
Page 7: Door Holder Output
AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL DOOR HOLDER OUTPUT The NZ100 system provides a door holder output, marked D.H on P.C.B. This can provide 12V(nominal) @250mA. This output is switched off during an alarm. It is also switched off ten minutes after mains failure is detected to conserve battery power. -
Page 8: Mains On Indicator
AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL 3.12 MAINS ON INDICATOR This LED is illuminated when the mains supply is connected and operational. 3.13 FUSING The NZ100 has five fuses: Door holder circuit fuse 0.25 Amp M205 Bell circuit fuse... -
Page 9: Connecting Devices
AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL CONNECTING DEVICES DETECTORS Devices such as heat detectors or manual call points which are normally closed, open circuiting for the alarm condition will give a fire signal within one second of operating. Devices, which increase the current in the detector line such as smoke detectors, may be operated with “gating”... -
Page 10: Settings
AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL SETTINGS The NZ100 system has two (2) link options. These are set by simply fitting or removing the jumper plug. If removing a jumper link, it is a good idea to refit it to one of the header pins. This will avoid losing the jumper, which may be required at a later date. -
Page 11: Installation And Initial Operation
AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL INSTALLATION AND INITIAL OPERATION INSTALLING THE NZ3200 Do not apply power or connect batteries during this procedure. Unpack NZ100. Check for transit damage. Drill all cable access and mounting holes. Mount the unit into position. -
Page 12: System Operation
AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL SYSTEM OPERATION RESETTING THE SYSTEM To reset the system after a fire, press the ‘RESET’ button on the API665. This will return the system back to its normal state. The buzzer will sound for confirmation. -
Page 13: Troubleshooting
AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL TROUBLESHOOTING Problem Possible cause/s Suggested remedy/ action Mains LED is off Mains supply is not operational. Check mains supply. AC Fuse on API 665 is blown. Check and replace if necessary F4 on API665. -
Page 14: Appendix A. Detector Circuit Limitations
AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL Appendix A. DETECTOR CIRCUIT LIMITATIONS. Detector Type Quiescent Current Circuit Limit Thermal Detector No limit (opening on alarm) Manual Call Point No limit Apollo Series 60 Heat Detector 57mA (55000-105) Apollo Series 60 Heat Detector... - Page 15 AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL Appendix A. DETECTOR CIRCUIT LIMITATIONS. Detector Type Quiescent Current Circuit Limit Thermal Detector No limit (opening on alarm) Manual Call Point No limit Apollo Series 60 Heat Detector 57mA (55000-105) Apollo Series 60 Heat Detector...
- Page 16 AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL Appendix A. DETECTOR CIRCUIT LIMITATIONS. Detector Type Quiescent Current Circuit Limit Thermal Detector No limit (opening on alarm) Manual Call Point No limit Apollo Series 60 Heat Detector 57mA (55000-105) Apollo Series 60 Heat Detector...
- Page 17 AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL Appendix A. DETECTOR CIRCUIT LIMITATIONS. Detector Type Quiescent Current Circuit Limit Thermal Detector No limit (opening on alarm) Manual Call Point No limit Apollo Series 60 Heat Detector 57mA (55000-105) Apollo Series 60 Heat Detector...
-
Page 18: Appendix B. Compatible Output Devices
AMPAC INDUSTRIES LTD NZ 100 OPERATORS MANUAL Appendix B. COMPATIBLE OUTPUT DEVICES Product Code Description BE0001 Bell 12VDC 30mA Red 150 mm. DETSQ07 Sounder with AS2220 Evac tone 9-28VDC 18mA. SO0001 Horn Siren 12VDC 115mA Red. SO0003 Flush sounder White 12/24V DC.
