Handicare SystemRoMedic Eva400 User Manual page 16

Dimensions Eva600
124
550/21.6
1410 /55.5
0/0
D
510/20.1
320/12.6
550/21.6
980/38.5
D is movement in forward direction
* can be 50 or 100 mm lower
depending on the placement of the
mast in the base socket
** can be 50 or 100 mm higher
depending on the placement of the
mast in the base socket
*** is reference measure 700 mm
with max legspreading
U S E R M A N U A L SystemRoMedic
All dimensions are in mm/inch
Tolerance +/- 5 mm/ 0.2"
TM
