IST-2282.PM01.01
Led Giallo acceso: la calibrazione è fallita. In questo caso, dopo 8 secondi si riavvia automaticamente e dopo il
preriscaldo, ripetere la procedura di "Calibrazione" senza reinserire il "Codice". Se la condizione persiste, anche dopo
la sostituzione della cartuccia sarà necessario inviare il rilevatore al fornitore per la riparazione.
"VERIFICA" (Non serve Codice): questa funzione, serve per controllare la corretta risposta del rilevatore al Gas e
può essere eseguita sia dopo la "Calibrazione" sia dopo l'installazione, ma va eseguita soprattutto durante le manu-
tenzioni periodiche, perché è l'unico metodo per controllare l'effettivo funzionamento dell'apparato.
Infilare il TC011 sul portasensore, regolare il riduttore della Bombola (0,88%v/v Metano+Aria), in modo che il flusso-
metro indichi circa 0,3 l/min
Fig.2) si raggiunga il valore in mV indicato in
cato nella
Colonna 7
(±0,2mA) e la centrale, cui è collegato il rilevatore, indichi circa il valore in %LIE (± 2) indicato in
risultato è diverso, è opportuno eseguire la "Calibrazione". Terminata la "Verifica", chiudere la bombola, togliere il
TC011. Considerare che l'uscita, tornerà progressivamente a 4 mA.
Se si usa la specifica miscela Gas/Aria del gas da rilevare, il segnale d'uscita dovrà corrispondere al gas utilizzato.
(Esempio se si deve verificare un rilevatore per Idrogeno, utilizzando una bombola con H
Aria, l'uscita in mA dovrà essere circa 7,2 mA (ovvero circa 72 mV su "TESTmA").
EN
DESCRIPTION
The TS282P series is a three-wire 4÷20mA transmitter able to detect combustible gases by employing a catalytic
Pellistor sensor calibrated up to 100% LEL to different gases and find their best application in centralized alarm
systems for laboratories, manufacturing industries and environments to be protected from possible leakage of gas.
The instruments comprise of a thermoplastic case in which the electronic circuit and the terminals are mounted.
The enclosure has downward facing cylindrical sensor housing with inside a replaceable "Cartridge Sensor".
The instrument has a 4÷20mA linear output (S) with 100%LEL (Lower Explosive Limit) F.S. of detected gas. This out-
put is connectable to a remote Gas Central Unit as listed
using for the Test and Calibration routine, protected by a code, and 3 Led shows the working conditions:
Red LED "ALARM":
Green LED "ON":
Yellow LED "FAULT":
NOTES ON THE AVAILABLE MODELS
TS282PM (Methane CH
its LEL (Lower Explosive Limit) is 4.4%v/v (%volume).
TS282PG (GPL) is calibrated to detect LPG, a gas heavier than air and consists of a mixture of 20÷30% Propane
(C
H
) and 80÷70% Butane (C
3
8
for Propane and 1.4%v/v for Butane. Standard calibration to LPG is carried out for Butane gas.
TS282PI (Hydrogen H
the lightest gas. Its density as to air is 0.07 and its LEL (Lower Explosive Limit) is 4%v/v (%volume).
TS282PB (Unleaded Gasoline/Petrol) is calibrated to detect Gasoline vapours heavier than air and highly flam-
mable. Its density as to air about 2.8 and its LEL (Lower Explosive Limit) is about 1.2%v/v (%volume).
TS282PX can be calibrated to detect the gases listed in
OPERATIONAL DESCRIPTION
The catalytic Pellistor sensor is practically insensitive to humidity and temperature variations. The calibration is car-
ried out for the specific gas to be detected. Anyway, it can contemporaneously detect any other flammable gas that
should be present in the same environment.
Preheating: when powered, the sensor needs a time of preliminary heating of about 60 seconds. During this peri-
od the yellow LED "FAULT" flashes. After this period, the yellow LED light off, the green LED "ON" illuminates to in-
dicate normal functioning. After this period the unit is able to detect gas even if it attains the optimum stability con-
ditions after about 4 hours continual functioning.
Normal operation: the green LED "ON" should be light on.
The Red LED (ALARM) illuminates when the Gas concentration attains 20%LEL (only if it be activate by Dip-Switch).
Faults: the instrument signal different kind of failures, as listed below. The Yellow LED illuminates and the "S" out-
put falls down to 0mA.
Yellow LED illuminates each 4 seconds (with Green LED activate): this happens when the "Cartridge Sensor" has
overcome its period of life (about 5 years) and its correct operation is no longer guaranteed. The detector keeps on
operating normally but it is necessary to replace, as soon as possible, the "Cartridge Sensor" with a new one. The
type to be required is listed
Yellow LED activates, Green LED off (0mA output signal): this signal different kind of faults. 1) The Dip Switch set
up is wrong, please verify
a new "Cartridge Sensor" is installed or it is not correctly connected or a not compatible one is mounted. Please
check the cartridge connections and compatibility
necting the device. If the condition does not change, it will be necessary to replace the unit and/or send it back to
the supplier to repair.
Yellow and Green LED activates (0mA output signal): this happens when the "Cartridge Sensor" is not working.
First try to perform the procedure of "ZERO" as described in the section "Test and Calibration > Zero adjust" then
TECNOCONTROL S.r.l. Via Miglioli 47 SEGRATE ( MI )
Istruzione / User's Manual / Manuel d'utilisation
(vedi
Fig.3). Controllare, che con i puntali del voltmetro sui Test-Point "TESTmA",
Tabella 3-Colonna
20% LEL alarm indication.
normal working condition
the sensor should be faulty, disconnected, out of scale or expired.
) is calibrated to detect Methane, a gas lighter than air. Its density as to air is 0.55 and
4
H
). Propane density as to air is 1.56 while Butane' is 2.05. The LEL is 1.7%v/v
4
10
) is calibrated to detect Hydrogen, is a colourless, odourless, highly flammable gas and is
2
nd
in Table 3 (2
column). The replacement procedure is described in the attached manual.
(see Table
2). 2) The "Cartridge Sensor" is not working, please replace with new one. 3) If
6. [ovvero che l'uscita in mA aumenti fino a circa il valore indi-
in Table
1. On the front panel there are two F1 e F2 key,
Table
3.
(see on page
1) these checks are made connecting and discon-
Tel. +39 02 26922890 - Fax +39 02 2133734
Pag.4/10
(vedi
Colonna 8
]. Se il
a 0,8%v/v (=20%LIE) in
2
