What happens if power is down?

If power is down the diodes are turned off. The internal clock continues to keep correct time at
least during 24 hours. When power is up again correct time is displayed directly.
When synchronised to minute impulse (slave): The clock stops when the power failure occurs.
When power is up again, the clock is adjusted to correct time by means of rapid impulses from
the master clock.
If the power failure lasts for more than 24 hours, time has to be programmed manually.

Technical specification

Data
Main power
Power consumption
Size of digits
Diode light intensity (red)
Power consumption (impulse)
Synchronisation
Running reserve
Accuracy
Protection class
Standards compliance
Weight
Dimensions
* option
** factory mounted option
WESTERSTRAND URFABRIK AB
P.O. Box 133
SE-545 23 TÖREBODA
Polarised impulse 1/1, ½, min, 24-48V,
Time code via LON**, LTC (SMPTE/EBU)**
0,1 sec/ 24 h quartz crystal reference
Tel. +46 (0)506 48 000
Fax. +46 (0)506 48 051
All versions
230VAC 50Hz –10% +5%
10VA
60 mm
300 mcd
5 mA at 24V. 10 mA at 48V.
Radio DCF*, RDS*
Time code via IRIG-B-input**
Time code via RS485-input**
24 h internal time keeping
IP43
EN50081-01 and EN50082-02
3,4 kg
344x344x70 mm
Internet::
E-mail:
Document: 1554en05.doc
Author.: CAn
Date: 2004-02-17
Page: 7 of 7
