HZ-FP-G Series
Faceplate for Horizon™ In-Wall Devices
Crestron® HZ-FP-G series faceplates are essential installation
components for Horizon™ devices. Horizon faceplates provide a finished
appearance with customizable design elements.
HZ-FP-G faceplates are available in single- or multigang sizes and provide
perfect alignment of the keypad(s) within the faceplate.
In the Box
1
HZ-FP-G1, HZ-FP-G2, HZ-FP-G3, or HZ-FP-G4,
for Horizon In-Wall Devices
Additional Items for HZ-FP-G1
1
2
Trim Plate, Smooth
1
2
Trim Plate, Textured
2
Screw, 4-40 x 1/4 in., Undercut Head, Phillips (2050242)
1
Plate, Metal, Mounting, Upper, 1 Gang (2052837)
1
Plate, Metal, Mounting, Lower, 1 Gang (2052838)
Additional Items for HZ-FP-G2
1
2
Trim Plate, Smooth
1
2
Trim Plate, Textured
4
Screw, 4-40 x 1/4 in., Undercut Head, Phillips (2050242)
1
Spacer, Multigang Alignment (2049924)
1
Plate, Metal, Mounting, Upper, 2 Gang (2052839)
1
Plate, Metal, Mounting, Lower, 2 Gang (2052840)
Additional Items for HZ-FP-G3
2
Trim Plate, Smooth
2
Trim Plate, Textured
4
Screw, 4-40 x 1/4 in., Undercut Head, Phillips (2050242)
2
Spacer, Multigang Alignment (2049924)
1
Plate, Metal, Mounting, Upper, 3 Gang (2052841)
1
Plate, Metal, Mounting, Lower, 3 Gang (2052842)
Additional Items for HZ-FP-G4
2
Trim Plate, Smooth
1
Faceplate
2
Trim Plate, Textured
8
Screw, 4-40 x 1/4 in., Undercut Head, Phillips (2050242)
3
Spacer, Multigang Alignment (2049924)
1
Plate, Metal, Mounting, Upper, 4 Gang (2052843)
1
Plate, Metal, Mounting, Lower, 4 Gang (2052844)
2
1. Refer to the HZ-FP-G1, HZ-FP-G2, HZ-FP-G3, or HZ-FP-G4 product page at
crestron.com
2. Black faceplates use Screw, 4-40 x 1/4 in., Undercut Head, Phillips, Black
(2007152)
2
Quick Start
1
1
1
1
for a complete list of color and texture variations.
2
2
1
