Intense PRIMER S User Manual page 12

getting to
know your
primer 275
Frame Features //
• Rear Travel: High Setting of
Flip Chip: 140 mm 5.5 inches
with 210 x 50 stroke shock
• Rear Travel: Low Setting of Flip
Chip: 137 mm 5.4 inches with
210 x 50 stroke shock
• Wheel Size: 27.5"
• Frame Hub Spacing: Integrated
BOOST 148 x 12 dropouts
• Internal cable routing
1 2 // 2 0 2 1 p r i m e r
• Internal seattube cable routing
for dropper posts
• Monocoque front triangle
• Water bottle mount
• Flak guard downtube,
chainstay, seatstay and
seattube protection
• Tapered headtube
• Max bearings and dedicated
frame hardware
u s e r m a n u a l
C o m p o n e n t S p e c n o t e
The Primer 275 is designed around the use of a single chain ring only. Use
of a double or triple ring set will not allow proper clearance with the frame.
W a r n i n g
Not intended for use with forks larger than 150 mm of travel.
Component spec //
• Fork: FOX 34 150 mm with
44 mm fork offset, 543.6 mm
axle to crown
• Rear Shock: 210 x 50, 20 mm x
8 mm rear reducer and 20 mm
x 6 mm for front triangle mount
• Headset: Cane Creek, 40, Alloy
Cartridge, ZS 44 Upper/ EC 49
Lower (www.canecreek.com)
• Bottom Bracket: Threaded 73 mm
• Rear Axle: BOOST 148 x 12
• Brake Mount: Post mount for
160 mm rotor
• Crankset: BOOST 148
(single ring only)
• Rear Wheel: BOOST 148
• Seatpost: 31.6 mm
