A EMS port communication status.
B Total energy the inverter has produced.
C Battery parameters, voltage and current are displayed
alternatively.
D Direction of the battery energy.
E BMS Status.
if this label is not shown, BMS Connections should be
checked.
F SOC of the Battery.
G PV panels parameters, voltage and current are displayed
alternatively.
H PV panels status.
If there's no PV voltage, this label will not be shown.
I Total PV power generation
J Default as current time, when an error occurred, fault
code will be displayed alternatively.
K Default as current date, when an error occurred, fault
code will be displayed alternatively.
L Direction of the grid power.
M Grid status. If there's no grid, this label will not be shown.
N Grid parameters, voltage and current are displayed
alternatively.
O Direction of the load power. If PV Inverter is installed, it
could feed power back into the grid.
P Indicating local load.
Q Load parameters, voltage and current are displayed
alternatively.
R Current power of the inverter.
