BullFrog I 331 Series Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Bullfrog Spas
Owners Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the I 331 Series and is the answer not in the manual?

Questions and answers

John
January 16, 2025

How can I change my temp. reading from centigrade to fareneight ?

0

Related Manuals for BullFrog I 331 Series

Summary of Contents for BullFrog I 331 Series

  • Page 1 Bullfrog Spas Owners Manual...
  • Page 2 QuICk rEfErEnCE To assist you with the installation and maintenance service of your new spa, please fill out the following information and keep it on hand for future reference. Spa Information Spa Model: Serial Number: Dealership: Dealer’s Phone Number: Date Purchased: Date Installed: Contractor Information Concrete, Decking, and Masonry...

  • Page 3: Table Of Contents

    TaBLE of ConTEnTS Important overview ..............2 Spa Maintenance Draining & Changing Spa Water ..........26 Important Safety Instructions Filter Maintenance ..............27 Safety Instructions ..............3 Light Replacement ..............28 Warning Signs ................6 Spa Shell Care ................28 JetPak Plumbing Care ..............29 Spa Start up Spa Cabinet Care ..............29 Spa Overview ................7 Spa Cover Care .................29...

  • Page 4: Important Overview

    Owner’s Manual or any other printed instruction, notice or bul- letin from Bullfrog Spas. Your spa’s serial number is located both on the base under the equipment door and the Manufacturing ID Label located inside the...

  • Page 5: Important Safety Instructions

    IMPorTanT SafETY InSTruCTIonS Save these instructions DANGER: Risk of Electric Shock. As per UL requirements (U.S.), install spa at least 5 feet (1.5m) from all metal surfaces. A spa may be Safety Instructions installed within 5 feet (1.5m) of metal surfaces if each metal surface is permanently connected by a minimum of No.
  • Page 6 WARNING: Risk of Fatal Hyperthermia. Hyperthermia occurs Before entering the spa, measure the water temperature with an ac- when the internal temperature of the body reaches a level several degrees curate thermometer since tolerances of water temperature regulating above the normal body temperature of 98.6˚ F (37˚ C). The symptoms of devices may vary.
  • Page 7 CAUTION: Non-Approved Accessories. Using accessories not wire equivalent in size to the circuit conductors supplying this approved by Bullfrog International, LC could void your warranty or cause equipment. other problems. Please consult your authorized Bullfrog Spa dealer.

  • Page 8: Warning Signs

    All of these warning signs are suitable for indoor and outdoor use. Place these warning signs in a noticeable place adjacent to the spa. For free additional copies, contact your authorized Bullfrog Spa Dealer. REDUCE THE RISK OF ELECTROCUTION 1.

  • Page 9: Spa Start Up Spa Overview

    SPa STarT uP Spa overview Filter Cap Cup Holder Filter Weir Door Auxiliary Control Pad* Foot Jets SnapCap Master Control Pad Pillow Light Ozone Jet* Suction Fitting Floor Drain JetPak *optional...

  • Page 10: Equipment Compartment

    Equipment Compartment Ozone Light Safety Certificate Pump 2 Valve Keeper Circ Pump* Control Center Union Pump 1 Product Info Heater Slice Valve *optional...

  • Page 11: Filling Your Spa

    If a leak is detected, tighten the fit- ting by hand. If the leak persists contact your authorized Bullfrog Spas Dealer. Step 2: Check Slice Valve Keepers: Verify that a slice valve keeper is installed on each slice valve.

  • Page 12: Control System

    The system keeps track of timeouts regardless of other conditions. IMPORTANT: Your Bullfrog Spa is equipped with one of 3 types of control pads, SELECT (4 Button), CLASSIC (6 Button), or PREMIER (8 Button).
  • Page 13 • Spa Operating Modes Sleep Mode (SLP): heats the spa during filter cycles to about 20°F (11°C) A multi-button sequence is used to switch between Standard, Economy, and lower than the set temperature. The Sleep Mode uses the least electricity Sleep modes.
  • Page 14 LED Light (optional) Freeze Protection Press light button to turn the LED light on and off. To toggle between all If the temperature drops to 44°F (7°C) within the heater, the pump(s) the LED color options, press the light button on, then off, then wait about 1 automatically activates to provide freeze protection.
  • Page 15 Classic Control System (6 Buttons) ing mode early. Once the Priming Mode is finished, the control system will turn on the pump 1 and begin to heat the water in Economy mode. General To speed up the water heating process during the initial startup or after a water change, change the spa operation mode to Standard mode and allow the spa to heat until the water reaches the desired temperature.
  • Page 16 the set temperature and is always ready for use. The drawback of Standard Jets Mode is the pumps and heater cycle on every thirty minutes throughout Press jets to turn pump 1 on and off and to shift between low and high speeds. If the day, and therefore this mode uses more electricity than other modes.
  • Page 17 Premier Control System (Series I Spas) number of filter cycles per 24 hour period. The display will show three options: “dn” (for day and night),” d” (day only), or “n” (night only). Press jets 1 to select General desired option. Press jets 1 again to exit the program. NOTE: For most applications, “dn”...
  • Page 18 exit the Priming mode early. Once the priming mode has completed, the Spa Operating Modes control system will turn on the filter pump and begin to heat the water in Press mode/prog to enter mode programming, then press cooler to cycle Standard mode.
  • Page 19 2 hours twice per day for non-circ pump models and 6 detect the spa temperature and will heat to set temperature (if needed). hours twice a day for circ pump equipped models. Bullfrog also recommends Jets 2/Aux (only available on two pump spas)

  • Page 20: Spa & Yard Stereo I

    Spa & Yard Stereo I System (optional) ™ LED Light (optional) Press light button to turn the LED light on and off. To toggle between all the LED color options, press the light button on, then off, then wait about 1 The Spa &...

  • Page 21: Spa & Yard Stereo Ii

    Step 2: Continue to push the left speaker down until both speakers are re- turned to the “yard” position and the left speaker is locked securely in place. NOTE: The speaker locking mechanism only engages when speakers are situ- ated in the “yard” position and affects only the left speaker. Spa &...

  • Page 22: Jetpaks & Jetting Interchanging Jetpaks

    JETPakS & JETTInG Interchanging JetPaks Step 4: Loosen the two PVC unions, pull the manifold out from in between the two water unions. NOTE: Due to the additional space requirements of plumbing and jets, the Step 5: Disconnect the air line union and remove the JetPak from the JetPod. NeckBlaster, NeckMasseuse, and Reliever JetPaks will only fit in the Lounger seats or the Recliner seats (corner seats) and not in the side seat locations.

  • Page 23: Jets

    Paks. The in-line filter should be cleaned anytime the waterfalls seem to have damage to the pump(s) may occur. If you are missing this divider or have reduced flow and/ or the waterfalls seem disrupted. questions, please call your authorized Bullfrog Spas Dealer.
  • Page 24 Step 1: Remove the JetPak and locate the in-line debris filter screen on the back of the JetPak. Step 2: Unscrew the fitting to expose the strainer. Step 3: Manually remove any visible particles and debris. Rinse to remove smaller particles. Step 4: Replace filter screen and re-tighten fitting.

  • Page 25: Water Care & Chemistry Chemicals

    For specific help in maintaining water quality, consult your Authorized Bull- frog Spa dealer who can recommend the correct products and procedures for Step 2: If possible, have your authorized Bullfrog Spa dealer test the Calcium sanitizing and maintaining your spa.

  • Page 26: Super Sanitation

    2-3 times a week. For each additional use, test the water one additional Chlorine in the spa can cause surface damage and component failure. time. Test kits and supplies are available from your authorized Bullfrog dealer. Baquanide (Baqua) products are also not recommended for use in your pH Control: Proper pH balance is extremely important in controlling bacte- Bullfrog Spa.

  • Page 27: Water Chemistry Troubleshooting

    With ozone, it may not be necessary to shock the water on a weekly contaminated the water. To remove these substances, Super Sanitize the water. basis, contact your authorized Bullfrog Spa dealer for more information. Second, non-filterable micro-particulate waste (e.g. dust) has contaminated the water.

  • Page 28: Spa Maintenance

    SPa MaInTEnanCE WARNING: An empty spa (spa without water in it) must not be left exposed to sunlight as shell damage may occur. Once the spa is unwrapped, fill spa with water immediately or shade the spa with cover or wrapping to prevent direct exposure to sunlight.

  • Page 29: Filter Maintenance

    It is recommended that pleated filter cartridge(s) be cleaned every 3-6 weeks or as needed. Replace the filter cartridge(s) every 1-2 years or when necessary. To maintain warranty protection, use only genuine Bullfrog Spas Filter Cartridge replacements. To clean or replace your filter cartridge(s), complete the following: CAUTION: Never operate spa with the filter(s) removed.

  • Page 30: Light Replacement

    To remove calcium deposits, soak cartridge(s) in a plastic container using a 1:10 ratio of Muriatic acid to water solution. Calcium deposits indicate a NOTE: For alternate lighting systems, contact your authorized Bullfrog Spas high spa pH, which should be corrected.

  • Page 31: Jetpak Plumbing Care

    Shell Care. Step 3: Clean the top (vinyl) of the cover with a mild solution of dishwashing soap, or other cleaner recommended by your local authorized Bullfrog Spas Spa Cabinet Care Dealer. Apply cleaner with a soft bristle brush. Using a gentle circular motion, scrub the cover, being careful to not let any of the cover dry before rinsing The EternaWood™...

  • Page 32: Freeze Prevention

    If you do malfunctioned may be subject to damaged plumbing or equipment as a result not have a spa vacuum, contact your authorized Bullfrog Spas Dealer. of ice buildup within the spa. If the spa cannot be checked and maintained on a weekly basis, then consider winterizing the spa.
  • Page 33 Step 4: Remove filter cartridge(s) and clean. Step 5: Secure the cover to the spa utilizing the tie downs and locking system. In areas where heavy snow is anticipated, place a large piece of plywood (or its equivalent) on top of the spa cover to assist in supporting the cover with the add- ed weight of the snow.

  • Page 34: Reference Material Site Selection & Installation

    (or, avoid Your Bullfrog Spas is the most leak-free spa in the industry, but there is still positioning your spa in an area where debris will be tracked into the spa).
  • Page 35 • All other national and local rules that may be applicable. form the electrical installation and GFCI test procedure. Each Bullfrog Spa is manufactured and tested to a standard that provides maximum protection Water Drainage: Your spa contains an equipment compartment, which houses against electrical shock.
  • Page 36 Spa Technical Specifications Chart or contact your local authorized Bullfrog Spas Dealer). If your spa’s pad is slightly sloped it may not affect the performance of the spa or its structure, however, there should be no dips, sags, or unevenness in the pad.
  • Page 37 To find the weight bearing load requirement along with the maximum filled weight of your spa, refer to the Spa Technical Specifications Chart or contact an authorized Bullfrog Spas Dealer. CAUTION: Consult a qualified Structural Engineer or Contractor before the spa is placed on an elevated structure or deck.

  • Page 38: Delivery Basics

    Delivery Basics to go over a wall, either because the entry area is too narrow, the eaves are too low, the corner is too tight, or the stairway is too steep. The use of a crane is a common practice and is usually the easiest and safest method for moving a spa To prepare for the delivery of your spa, make sure the delivery path is clear when access is difficult.

  • Page 39: Spa Dimensions Chart

    NOTE: The height of the cart used to dolly your spa into position will need to be added to the height of your spa when calculating the total height clearance required to com- plete your delivery. Spa carts are typically around 6 inches (15cm) in height. (If necessary, see your authorized Bullfrog Spas Dealer for the exact height.)

  • Page 40: Electrical Chaseways

    Electrical Chaseways Drilling Conduit Hole: All dimensions are at the bottom base. 1” (2.54cm) Conduit Drill 1-3/8” (3.49cm) hole 3/4” (1.91cm) Conduit Drill 1-1/8” (2.86cm) hole Center of hole is 1” (2.54cm) from the ground...

  • Page 41: Electrical Requirements

    • Service Disconnect: Based upon your area, a disconnect device must be Each Bullfrog Spa is manufactured and tested to a standard that provides incorporated into the fixed wiring in accordance with national and local wir- maximum protection against electrical shock. Improper wiring may prevent ing rules.
  • Page 42 Bullfrog Spa dealer or Electrician can easily WARNING: Removal or bypassing the GFCI will result in an unsafe spa convert the spa to operate on 30A (conversion instructions are located inside and will void your spa’s warranty. When installing the GFCI, all conductors the Control System Box).
  • Page 43 30mA. by any other electrical appliance) or the spa may not function properly. Installation must be in accordance with all national and local wiring rules. WARNING: Never use an extension cord. Bullfrog International, LC does...
  • Page 44 240V~/60Hz Pump: Spas equipped with a 240V~/60Hz pump can only be or the spa may not function properly. For specific conversion instructions, Permanently-Connected.240V~/60Hz Permanently-Connected Installation: please refer to the system wiring diagram inside the Control System Box (lo- Your spa has been configured to operate only on 240V~/60Hz power. cated in the spa’s equipment compartment).
  • Page 45 Step 5: Turn dip switch A12 to “off ” position, then power up spa for normal start up. Step 3: Turn dip switches A2 and A3 to “off ” (down) position. NOTE: This conversion must be performed by an authorized Bullfrog Spas Dealer.
  • Page 46 GfCI Wiring Diagrams House Breaker Box System Box RED (HOT) BLK (HOT) Circuit Board G.F.C.I. Breaker Box Elite System In Spa System Box WHITE (NEUTRAL) 2 BLACK (HOT) 3 RED (HOT) 4 GREEN (GROUND) 5 Note: For a 240V~ dedicated hookup, the white neutral wire is not required between the G.F.C.I.
  • Page 47 BfG15 Wiring Diagram (Europe/australia) BFG15 — PN 55556-01 ML (MAIN) PANELS J70, J71 04/29/09 J82 ON 2 PINS USE COPPER CONDUCTORS ONLY. SWITCHBANK A OFF (DOWN) SWITCHBANK A ON (UP) EMPLOYER UNIQUEMENT TEST MODE OFF TEST MODE ON DES CONDUCTEURS DE CUIVRE. F7 10A F1 3A SEE AMPERAGE SELECT...
  • Page 48 Spa & Yard Stereo I Wiring Diagram Connections Din cable connection for SIRIUS control Din cable connection for IPOD control AUX-IN Connection Sub Woofer USB Connection Antenna socket Hardware Reset Din cable connection for remote control...
  • Page 49 Spa & Yard Stereo II Wiring Diagram...

  • Page 50: Diagnostic Messaging

    Do noT EnTEr THE WaTEr. Remove the spa cover and allow water to cool. At 107°F (41.7°C), the spa should overheat - The spa has shut down. One of the sensors has automatically reset. If spa does not reset, shut off the power to the spa and contact your authorized Bullfrog detected that the spa water is 110°F (43.3°C).
  • Page 51 Diagnostic Message (for all control systems) Message Meaning Action Required The Priming mode will last for up to 4 minutes and then the spa will begin to heat and maintain the When your spa is first actuated, it will go into Priming water temperature in the Standard mode.
  • Page 52 WarnInG! SHoCk HaZarD! no user Serviceable Parts. Do not attempt service of this control system. Contact your authorized Bullfrog Spas Dealer or service organization for assistance. Follow all power connection instructions listed in this manual Installation must be performed by a licensed Electrician and all grounding connections must be properly installed.

  • Page 53: Troubleshooting Guide

    This guide will assist in solving simple problems with the spa. If the problem Cause #3: The pump motor is defective. cannot be solved using these procedures, contact your authorized Bullfrog Solution: Contact your authorized Bullfrog Spas Dealer. Spas Dealer.
  • Page 54 Spa pump will not turn on, creates a burning smell while running, or makes excessive noise while running: Cause: Pump motor is defective. Solution: Contact your authorized Bullfrog Spas Dealer. Jets are weaker than normal or do not work at all, but the pump is running: Cause #1: Jet handle(s) are partially or fully closed.

  • Page 55: Limited Warranty

    Paks is guaranteed for a minimum of one year. Color availability beyond one year is dependent upon market demand and availability of color to Bullfrog. The Bullfrog Spa Limited Warranty is one of the best in its class. It is five-Year EternaWood...
  • Page 56 Bullfrog or its authorized agent will repair or replace any malfunction or de- Spa limited warranty is void if any of the following occur: fective component on the Bullfrog Series I & Series II Spa that is covered un- der the terms of this limited warranty and was purchased from an authorized •...
  • Page 57 Damage is caused by failure to install, maintain and operate the spa in ac- FROG OR ITS AUTHORIZED AGENTS. cordance with the recommendations contained in the Bullfrog Series I & Legal rights Series II Owner’s Manual, Pre-Delivery Guide or any other printed instruc- tions, notice or bulletin from Bullfrog.

  • Page 58: Sport X

    ™ SportX Series mechanical equipment, and leaks from any component or Bullfrog warrants the SportX Series Spa shell not to leak and the UniFrame plumbing fitting located beneath the spa shell. Defective components that (injection- molded cabinet frame) against degradation for the life of the are easily removed from the spa, such as the spa lights (bulb and LED original retail purchaser of the spa.
  • Page 59 (at market) labor rate for all service work performed Damage is caused by an Act of God or any other cause beyond the control of Bullfrog. under the terms of this warranty and may also charge you a reasonable •...

  • Page 60: Obtaining Service

    If the spa falls within the warranty period and within the scope of the war- Disclaimers ranty, contact your authorized Bullfrog Spas Dealer to schedule a service call. BULLFROG AND ITS AUTHORIZED AGENTS SHALL NOT BE LIA- You will be required to show proof of purchase.
  • Page 64 Bullfrog International, LC 668 W. 14600 S. Bluffdale, UT 84065 T: 801.565.8111 F: 801.565.8333 E: info@bullfrogspas.com Register your spa online by visiting: bullfrogspas.com/register North America 2011...
