W3000
Freestanding
Insert
OWNER'S MANUAL
Warning: If your appliance is not properly installed a house fire may result. For your safety, follow
the installation directions. Contact local building or fire officials about restrictions and installation
inspection requirements in your area.
PLEASE read this entire manual before installation and use of this pellet fuel-burning room heater.
Failure to follow these instructions could result in property damage, bodily injury, or even death.
Save these instructions
PROFESSIONAL INSTALLATION IS HIGHLY RECOMMENDED
Manufactured by
National Steelcrafters of Oregon, Inc.
DBA Breckwell Hearth Products
Eugene, Oregon
Grand Prairie, Texas
BRECKWELL HEARTH PRODUCTS
CW-L-001
12/03
Advertisement
Table of Contents
Related Manuals for Breckwell W3000FS
Summary of Contents for Breckwell W3000FS
- Page 1 Failure to follow these instructions could result in property damage, bodily injury, or even death. Save these instructions PROFESSIONAL INSTALLATION IS HIGHLY RECOMMENDED Manufactured by National Steelcrafters of Oregon, Inc. DBA Breckwell Hearth Products Eugene, Oregon Grand Prairie, Texas BRECKWELL HEARTH PRODUCTS CW-L-001...
-
Page 2: Introduction
During the paint curing process, it will emit a non-toxic smoke. Opening a window near the stove will help this to dissipate. Only High Temp Paint, available from your Breckwell dealer, should be used for touch-ups. We recommend Stove Bright #6309 – Metallic Black. -
Page 3: Safety Precautions
NOT BE INSTALLED IN A BEDROOM (Per H.U.D. requirements). Check with local building officials. Breckwell Hearth Products grants no warranty, implied or stated, for the installation or maintenance of your stove, and assumes no responsibility of any consequential... -
Page 4: Safety Information
CAUTION: WHILE THE STOVE IS BURNING, THE DAMPER ROD MUST BE FULLY OPEN BEFORE OPENING THE DOOR TO AVOID COMBUSTION FLASH. Installation and repair of the W3000FS and W3000I Wood Stove should be done by a qualified service person. The W3000FS and W3000I, Chimney connector and chimney should be inspected by a qualified service person before the heating season, and at least once a month during the heating season to determine if a creosote build up had occurred. -
Page 5: Table Of Contents
TABLE OF CONTENTS INTRODUCTION -------------------------------------------------------------------------------------------------- SAFETY PRECAUTIONS ----------------------------------------------------------------------------------------- SAFETY INFORMATION ----------------------------------------------------------------------------------------- Creosote – Formation and Need for Removal INSTALLATION -------------------------------------------------------------------------------------------------- Specifications ---------------------------------------------------------------------------------------------- Clearances ------------------------------------------------------------------------------------------------ Venting ----------------------------------------------------------------------------------------------------- Freestanding Installations Insert Installations Pedestal Assembly -------------------------------------------------------------------------------------- Optional Blower Installation Outside Air Kit -------------------------------------------------------------------------------------------- Special Mobil Home Requirements Installing the Brick Panels OPERATION... -
Page 6: Installation
NOTE: Materials projecting more than ¾” from the wall are considered mantels. W3000I 24” 32” 18” W3000I w/Heat Shield* 16” 24” 18” *Use only the Breckwell Heat Shield – Part Number CW-S-157. INSTALLATION 16” 14” 7” 16” 84” 30” 12” 10” 7”... -
Page 7: Venting
FIGURE 3 VENTING FREESTANDING The W3000FS is approved for use with double wall connector and the same manufacture’s chimney systems as follows: Simpson Dura-Vent Model DVL Selkirk Metalbestos DS Security Chimneys Model DL Install the chimney by following the manufacture’s instructions. -
Page 8: Pedestal Assembly
PEDESTAL ASSEMBLY – W3000FS Note: The W3000FS wood stove is heavy. Be prepared to handle the weight to avoid damage or injury. Wearing gloves during installation is recommended. Carefully lay the stove on its back on carpet or other material that will prevent damage to the finish. -
Page 9: Special Mobil Home Requirements
W3000FS. Use only the holes provided. If the optional blower is used the W3000FS must be grounded to the steel chassis of the home with 8 Ga. Copper wire using a serrated or star washer to penetrate paint or protective coating to ensure grounding. -
Page 10: Operation
Some of the things that can affect natural drafting are size and length of the chimney, nearby obstructions, and geographical location. Your Breckwell dealer will be able to help you match your stove to a proper chimney system. -
Page 11: Maximizing Your Stoves Efficiency
This no longer applies to your new Breckwell stove. It is still important to have the stove hot enough to burn efficiently, but this will now take less pre-heating than older stoves. -
Page 12: Maintenance
During every chimney cleaning the ceri-blanket should be inspected. If it has become compressed or heavily stained it needs to be replaced. GASKETS Periodically check the door gasket to make sure it is not over compressed (causing the door to leak). Your Breckwell dealer can supply you with the correct gasket for replacement. Never use substitute materials. -
Page 13: Replacement Parts List
REPLACEMENT PARTS Contact an Authorized Breckwell Pellet Stove Dealer to obtain any of these parts. Never use substitute materials. Use of non-approved parts can result in poor performance and safety hazards. ITEM Blower Kit – W3000FS – Optional Blower Kit – W3000I – Optional...
