OWNER'S OPERATION AND INSTRUCTION MANUAL
BRECKWELL
CAUTION!
Please read this entire manual before you install
or use your new room heater.
instructions may result in property damage,
bodily injury, or even death.
Improper Installation Could Void
Your Warranty!
SAFETY NOTICE:
If this heater is not properly installed, a house
If this heater is not properly installed, a house
fi re may result. For your safety, follow the
fi re may result. For your safety, follow the
installation instructions. Never use make-shift
installation instructions. Never use make-shift
compromises during the installation of this
compromises during the installation of this
heater. Contact local building or fi re offi cials
heater. Contact local building or fi re offi cials
about permits, restrictions and installation
about permits, restrictions and installation
requirements in your area.
requirements in your area.
SAFETY TESTED TO UL 1482-2011, UM-84, ULC-S627-2000, and ULC-S628
US ENVIRONMENTAL PROTECTION AGENCY PHASE II CERTIFIED WOODSTOVE
THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE
YOU TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
French version is available for download from the Breckwell website: http://www.breckwell.com/
La version française est disponible pour téléchargement à partir du site Breckwell: http://www.breckwell.com/
Breckwell
P.O. Box 750
Bridgeport, AL 35740
Phone: (866) 606-8444
www.BRECKWELL.com
Exceptional Heat, Outstanding Value
MODEL: SW740
Failure to follow
Approved for installation in the USA and Canada
WASHINGTON STATE APPROVED
MOBILE HOME APPROVED (U.S. ONLY)
SAVE THESE INSTRUCTIONS.
®
852053C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Breckwell SW740
Summary of Contents for Breckwell SW740
- Page 1 YOU TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE. French version is available for download from the Breckwell website: http://www.breckwell.com/ La version française est disponible pour téléchargement à partir du site Breckwell: http://www.breckwell.com/ Breckwell P.O. Box 750...
- Page 2 DO NOT LEAVE THE STOVE UNATTENDED WHEN THE DOOR IS SLIGHTLY OPENED. • DO NOT BURN GARBAGE, FLAMMABLE FLUID SUCH AS GASOLINE, NAPHTHA OR MOTOR OIL. • DO NOT CONNECT TO ANY AIR DISTRIBUTION DUCT OR SYSTEM. • ALWAYS CLOSE THE DOOR AFTER THE IGNITION. Breckwell...
- Page 3 You may use an envelope if you choose. You may register online by going to www.breckwell.com All information submitted will be kept strictly confi dential. Information provided will not be sold for advertising purposes.
- Page 4 Fold Here Fold Here Fold Here PLACE STAMP HERE Breckwell P.O. Box 750 Bridgeport, AL 35740 Breckwell...
-
Page 5: Unpack And Inspect
9. A non-combustible fl oor protector as specifi ed in this manual. 10. All chimney and chimney connector components required for your particular venting installation. 11. For mobile or manufactured home installations, see the MOBILE HOME section in this manual. Breckwell... - Page 6 Attach the pedestal back to the pedestal using four(4) sheetmetal screws provided. Make sure that the baffl e board, above the air tubes, is in place and undamaged. DO NOT remove the baffl e board. Breckwell...
- Page 7 4. Reinstall the damper plate(26304) and retaining screws(83343). 5. Finally reinstall the front plate and the two retaining screws. 1.50 CUT HERE PULL BACK INSULATION RETAINING SCREWS BEHIND INSULATION Damper Plate (26304) Air Dam (26346) Front Plate (26302) Insulation (88190) Breckwell...
- Page 8 INSERT STOVE FACADE ASSEMBLY Breckwell Room Heaters are available as an insert into existing masonry or factory-built fi replaces. Do not alter the existing fi replace in any way either by removing bricks or mortar which could weaken the structural integrity of the fi...
- Page 9 Self-adhesive insulation Top Panel Retainer Attach facade trim. Align mounting screw with center of predrilled mounting hole. Breckwell...
-
Page 10: Installation
Canadian Installations require a minimum of 450 mm [18”] beyond the front of the unit and 200mm [8”] beyond each side of the unit. A Floor Protector of 1/2 inch thick is recommended for this installation. Breckwell... -
Page 11: Clearances To Combustibles
For Canadian installations, where passage through a wall, or partition of combustible construction is desired, the installation must conform to CAN/CSA-B365. • A fl ue pipe crossing a combustible wall must have a minimum clearance of 18” (457.2mm). • To reduce fl ue clearances from combustible materials, contact your local safety department. Breckwell... -
Page 12: Floor Protection
When in MASONRY fi replaces, use a fl oor protector listed to standard UL 1618. When in Factory-built fi replaces, use a fl oor protector listed to standard UL 1618. See ALTERNATE FLOOR PROTECTOR CALCULATIONS section in this manual for instructions on how to calculate acceptability of alternate materials. Breckwell... -
Page 13: Mobile Home Installation
• Outside Air is mandatory for mobile home installation. See your dealer for purchasing. (see Ventilation Section for details) • Check with your local building offi cials as other codes may apply. MOBILE HOME MOUNTING BOLT HOLES Breckwell... - Page 14 Adapter. Follow the manufacturer’s installation instructions for attaching the dryer vent kit to the home. Then, attach it to the adapter on the appliance. The dryer vent kit can be installed on either the back of the pedestal or on the Outside Air Assembly on the free standing leg option. Breckwell...
-
Page 15: Chimney Connector (Stove Pipe)
Installation of a “barometric draft stabilizer” (fi replace register) on a smoke exhaust system is prohibited. Furthermore, installation of a draft damper is not recommended. Indeed, with a controlled combustion wood stove, the draft is regulated upon intake of the combustion air in the stove and not at the exhaust. Appliance Breckwell... - Page 16 6. Using a fi re screen at the extremity of the chimney requires regular inspection in order to insure that it is not obstructed, thus blocking the draft; and it should be cleaned when used regularly. 7. Exterior chimney should be double or triple wall. Breckwell...
-
Page 17: Installation Into A Masonry Fireplace
MUST have a warning plate permanently installed in a Breckwell recommends the use of a full liner where a stainless steel visible location stating that the fi replace is unfi t for use with rigid or fl... -
Page 18: Masonry Chimney
Make sure there are no cracks, loose mortar, or other signs of deterioration and blockage. Have the chimney cleaned before the stove is installed and operated. When connecting the stove through a combustible wall to a masonry chimney, special methods are needed. Breckwell... -
Page 19: Factory Built Chimney
fl ashing, chimney cap, etc. Maintain proper clearance to the structure as recommended by the manufacturer. The chimney must be the required height above the roof or other obstructions for safety and proper draft operation. See Chimney section for details. Ensure chimney is a minimum of 12’ tall. Breckwell... -
Page 20: Combustible Wall Chimney Connector Pass-Throughs
Connectors to a masonry chimney, excepting method B, shall extend in one continuous section through the wall pass-through system and the chimney wall, to but not past the inner fl ue liner face. A chimney connector shall not pass through an attic or roof space, closet or similar concealed space, a fl oor, or ceiling. Breckwell... -
Page 21: Testing Your Wood
If your wood hisses and water or vapor escapes at the ends of the piece, your wood is soaked or freshly cut. Do not use this wood in your stove. Large amounts of creosote could be deposited in your chimney, creating potential conditions for a chimney fi re. Breckwell... -
Page 22: The First Fires
Once the updraft movement is initiated, you are ready to ignite the stove by lighting the paper and kindling wood inside the combustion chamber. When you have achieved a good bed of hot embers, we recommend the following burn procedures: SW740 Primary Air Settings Electric Blower Speed Setting (Variable) (Slide Damper is located in center of stove under hearth plate) (Blower is on High when turned “ON”, Rotate... -
Page 23: Ash Disposal
Other waste shall not be placed in this container. It is strongly recommended that ashes in the metal container are taken outside immediately and are not stored within your home. CAUTIONS: • ASHES COULD CONTAIN HOT EMBERS EVEN AFTER TWO DAYS WITHOUT OPERATING THE STOVE. Breckwell... -
Page 24: Maintenance
The secondary air tubes must be cleaned with a wire brush. If debris remains in holes lightly tap with a wooden stick to remove. Firebrick The fi rebrick should be cleaned and inspected as necessary. Replace any damaged or broken brick. Breckwell... -
Page 25: Repair Parts List
IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING ORIGINAL MANUFACTURERS PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM THE APPLIANCE MANUFACTURER. USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY. 852049 Breckwell Logo 89066 Firebrick (4-1/2 X 9) 26304 Damper Rod Tensioner 86643 Tube (Ø5/32) , Secondary Air... -
Page 26: Repair Parts Diagrams
REPAIR PARTS DIAGRAMS Breckwell... - Page 27 Breckwell...
-
Page 28: How To Order Repair Parts
ATTACHED TO THE HEATER. WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION AS SHOWN IN THIS LIST: THE PART NUMBER THE PART DESCRIPTION THE MODEL NUMBER: THE SERIAL NUMBER: Breckwell P.O. Box 750 Bridgeport, AL 35740 Phone: (866) 606-8444 Web: www.BRECKWELL.com Breckwell...
