Faults
One LED illuminates red
During charging:
Battery is too hot or too
cold for the charging
process to start. Once the battery has
cooled down or warmed up, the charging
procedure starts automatically.
During operation:
Battery is overheated.
Machine switches off –
remove the battery from the lawn mower
and allow to cool for a few minutes.
Four LEDs flash red
The battery is defective
and must be replaced.
Three LEDs illuminate red
The lawn mower is
overheated – allow it to
cool down.
Three LEDs flash red
The lawn mower is
defective and must be
checked by a specialist
dealer. STIHL recommends STIHL
specialist dealers.

8.6 LED on the charger

The LED (3) indicates the charger
status. It can illuminate green or
flash red.
The LED illuminates green
and the LEDs on the battery
illuminate or flash green:
The battery is charging.
42
The LED flashes red:
There is no electrical contact
between the battery and the
charger, or there is a fault in
the battery or in the charger.
If the LED illuminates green and 1 LED on
the battery illuminates red, the battery is
too warm or too cold.
● Remedy the faults. (

9. Controls

9.1 Safety plug

The lawn mower can only be
operated when the safety plug is
inserted in the socket behind the battery
compartment.
Risk of injury!
The safety plug must be
removed prior to
performing any work on the
machine, particularly before
transport, maintenance or cleaning
work, as well as before inspecting
the machine. (
The cover of the battery
compartment is held in the closed
position by two magnets.
8
● Lift up the battery compartment
cover (1) and hold in the open position.
● Removing:
Remove the safety plug (2) from the
socket (3) and keep separately from
lawn mower.
Inserting:
Press the safety plug (2) as far as it will
go into the socket (3).
● Close the battery compartment

9.2 Eco mode switch

The eco mode switch that increases
battery running time is located in the
battery compartment. (
20.)
Switching on eco mode:
● Move switch to position I.
Switching off eco mode:
● Move switch to position 0.
9

9.3 Folding down the handlebar

The handlebar can be folded down
for space-saving transport and
storage of the mower.
4.)
● Switch off the motor immediately and
● Open the left and right quick-clamping

9.4 Adjusting the cutting height

cover (1).
10.2)
Danger of pinching!
The handlebar can fold down
uncontrollably when the quick-
clamping devices are released.
For this reason, always hold the
handlebar with one hand when you
release the fastening.
disconnect the safety plug. (
devices (1) and carefully fold the
handlebar (2) downwards to the front.
Risk of injury!
Stop the motor before adjusting the
cutting height.
0478 131 9939 A - EN
