Notes On Working With The Machine; General; Cutting Performance; Working Area For Operator - Stihl RMA 2 RT Instruction Manual

Four different cutting heights between
28 mm and 85 mm can be set.
Level 1 = lowest cutting height
Level 4 = highest cutting height
Risk of injury!
The setting on the front and rear
axles must be identical.
1 Setting the rear cutting height
● Set the required cutting height at the
rear axle (1).
For this purpose, support the machine
with one hand and move the rear axle to
the desired level on one side first and
then on the other.
Ensure that the rear axle is at the same
level on the left and right sides (rear
axle parallel to the housing).
2 Setting the front cutting height
● Push the cutting height adjustment
lever (2) outwards, move to the desired
level and allow it to engage.
10. Notes on working with
the machine

10.1 General

To ensure a perfect, thick lawn, mow
regularly and keep the grass short.
Do not cut the lawn too short in hot, dry
conditions as it will dry out or burn in the
sun and become unsightly.
The cutting pattern will be better with a
sharp blade than with a blunt one; the
blade should therefore be sharpened
regularly (STIHL specialist dealer).
0478 131 9939 A - EN

10.2 Cutting performance

The cutting performance (battery running
time) depends on the quality of the grass
and the selected cutting height. The
cutting performance is enhanced by the
following measures:
– Mowing the lawn more frequently
– Increasing the cutting height
– Reducing speed of propulsion
– Allowing the lawn to dry before mowing.
If required, additional STIHL lithium ion
batteries can be purchased (special
accessories).
Eco mode:
The lawn mower features an
eco mode, which improves its
energy efficiency and therefore
its cutting performance.
Eco mode can be switched on and off
using the switch in the battery
compartment. ( 9.2)
Function:
The speed of the motor is reduced
automatically when less power is required.
If more power is required, the speed is
increased again within a fraction of a
second.

10.3 Working area for operator

● For safety reasons, the operator
must stay within the working area
behind the handlebar when the motor is
running. Always observe the safety
distance provided by the handlebar.
● The lawn mower must only be operated
by one person. Other persons must
keep out of the danger area. (

10.4 Correct motor load

Do not switch the lawn mower on in tall
grass. Select a higher cutting height
setting if the motor is difficult to start.
The lawn mower load must never cause
the motor speed to drop significantly.
If the speed drops when mowing tall grass,
select a higher cutting height setting
and/or reduce the speed of propulsion.
When eco mode is switched on, the
speed is reduced automatically
when less power is required.
( 10.2)

10.5 If the mowing blade blocks

Switch off the motor immediately and
disconnect the safety plug. Then eliminate
the cause of the fault.
10.6 Thermal motor overload
protection
The electronics switch off the motor if it
becomes overloaded during operation.
Three red LEDs in the battery illuminate if
a thermal overload occurs. (
Causes for an overload:
– blunt mowing blade
– mowing excessively high grass or
cutting height adjusted too low
16
– excessive rate of feed
– inadequate cleaning of the cooling air
guide (inlet slots)
4.)
8.5)
43
