E / F Series
TRAFFIC BEACON QUICK START GUIDE
For the R920-E/F, R820-E/F, R829-E/F, and R247-E/F flashing beacons
F-Series
E-Series
84775_QSG_TRA_E-F-Series_RevD.docx
Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 |
customersupport@carmanah.com
| carmanah.com

Advertisement

Table of Contents
loading

Related Manuals for Carmanah E Series

Summary of Contents for Carmanah E Series

  • Page 1 E / F Series TRAFFIC BEACON QUICK START GUIDE For the R920-E/F, R820-E/F, R829-E/F, and R247-E/F flashing beacons F-Series E-Series 84775_QSG_TRA_E-F-Series_RevD.docx Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com | carmanah.com...
  • Page 2 E/F SERIES QUICK START GUIDE This page intentionally left blank. Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...

  • Page 3: Safety Precautions

    This quick start guide is not a replacement for the complete product user manual. Visit carmanah.com to download the complete product user manual. Tools and Materials Required The following tools and materials may be required to mount your Carmanah flashing beacon depending on the E/F Series model and configuration: a. Imperial socket set h.
  • Page 4  Remote systems are turning on and off correctly via wireless control if applicable.  For RRFB systems, verify the indicator LEDs on the ends of light bars can be seen by pedestrians across the street. Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 5 4. Install on post and orient solar engine to face South (for Northern Hemisphere locations). 5. Tighten set screws or bolts onto post. Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 6 3. Install mount onto square post and tighten bolts onto post. 4. Loosen less than one turn until solar engine faces South (for Northern Hemisphere locations). 5. Tighten top bolt on mount. Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 7 4. Thread solar engine all the way onto nut in channel. Loosen less than one turn until solar engine faces South (for Northern Hemisphere locations). 5. Tighten top hex nut down against mount. Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 8 6. Install on post, adjust the rotation of the signal head if required and adjust the rotation of the solar engine to face South (for Northern Hemisphere locations). 7. Tighten mount screws onto post, then tighten hex nut. Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 9 E/F SERIES QUICK START GUIDE Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 10 5. Adjust direction of signal if required, and orient solar engine to face South (for Northern Hemisphere locations). 6. Tighten nipple and top hex nut. Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 11 E/F SERIES QUICK START GUIDE Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 12 4. Adjust direction of the signal if required, and orient solar engine to face South (for Northern Hemisphere locations). 5. Tighten nipple and top hex nut. Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 13 E/F SERIES QUICK START GUIDE Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 14 If the pedestrian confirmation light is not required in one direction, use the supplied opaque label to cover the indicator light. Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com...

  • Page 15: Battery Installation

    1. Open the solar engine and install the batteries, connecting each battery using the correct polarity. Secure batteries with battery strap; note proper routing. 2. Batteries must be installed with the terminals facing outward (E Series, left image below) or upwards (F Series, right image below).

  • Page 16: Ems Programming And Testing

    The EMS OBUI has three buttons to navigate and change settings and activate functions as required. The Up arrow, Down arrow, and SET button are used to scroll through menus, access and change settings, and accept new settings. Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 17 E/F SERIES QUICK START GUIDE Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 18 Allows the system to run a number of self-tests and can be used for troubleshooting purposes. Firmware Version Displays the firmware version programmed on the system controller (EMS). Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...

  • Page 19: Troubleshooting

    The EMS is looking for the other fixture in the alternate pattern and declares an “LED Open” fault when it doesn’t find one. Set flash pattern to unison. showing on User Interface Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 20 E/F SERIES QUICK START GUIDE © 2020 Carmanah Technologies Corporation Technical Support: Email: customersupport@carmanah.com Toll Free: 1.877.722.8877 (US & Canada) Worldwide: 1.250.380.0052 Fax: 1.250.380.0062 Web: carmanah.com Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
