Settings For Photon Card Com1 & 2 Present - Brainboxes CC-618 Hardware Manual

PCI Photon 4 Port RS232
Settings for Photon Card COM1 & 2 Present
COM SISR
Port
BBCARDS FF80
Values*
COM3 FF80
COM4 FF80
COM5 FF80
COM6 FF80
*The BBCARDS Values may be different from your machine.
Card Port 1
Card Port 3
NOTE: The only settings that change from port to port are the COM
Base and the Card Port Settings
Card COM
Port Base
FFC0
1 FFC0
2 FFC8
3 FFD0
4 FFD8
Software Installation
IRQ UART
10
10 16950
10 16950
10 16950
10 16950
Card Port 2
Card Port 4
Chapter 3 Page 18
FIFO
Trip
Default
Default
Default
Default
