PCI Photon 4 Port RS232

Settings for Photon 4 Port RS232 Card COM1 Present

COM SISR
Port
BBCARDS
FFA0
Values *
COM2 FFA0
COM3 FFA0
COM4 FFA0
COM5 FFA0
*The BBCARDS Values may be different from your machine.
Card Port 1
Card Port 3
NOTE: The only settings that change from port to port are the COM
Base and the Card Port Settings
Card COM
Port Base
FF40
1 FF40
2 FF48
3 FF50
4 FF58
Software Installation
IRQ UART
11
11 16950
11 16950
11 16950
11 16950
Card Port 2
Card Port 4
Chapter 3 Page 17
FIFO
Trip
Default
Default
Default
Default
