PCI Quad RS232
PCI QUAD RS232 HARDWARE
CONFIGURATION.

Introduction.

This chapter explains how to configure the PCI QUAD RS232 in a
PC compatible.
This three quarter size RS232 card will work happily in any PC
compatible up to and exceeding Pentium III 550 MHz class
machines.

PCI QUAD RS232 Card Features.

Four independent modified RS232 Serial ports.
Reliable communications up to 50 feet, 15m, and beyond!
100% PC Compatible serial port TI 16C554, up to 115,200
baud.
Fully Plug and Play
Operationally PCI 2.1 compliant
Modem control TXD, RXD, DSR, DTR, RTS, and CTS
signals.
Fully double buffered for reliable asynchronous operation.
High-speed integrated circuitry ensures operation with fast
PC's e.g. 550 MHz Pentium III WITHOUT extra wait states.
16554 FIFO provides 16-byte input and 16-byte output buffer
on each port.
Hardware Configuration
CHAPTER 1
Chapter 1 Page 8
