Cobra Systems VNM 4 Pro SignMaker User Manual page 6

Loading VnM 4 Ink Roll
®
1
3
5
7
NOTE: Always have the VnM printer cover closed when powering on.
5
Always
turn off
printer when
changing Ink
Rolls! Open
the ribbon
access cover.
Load rear ink
spindle with
the new ink
roll.
Tape the
ink to empty
take-up
core.
Wind the
front ink
spindle to
take up the
slack,
making
sure there
are no
wrinkles in
the ink.
Copyright © 2020 Cobra Systems, Inc. All rights reserved
2
4
6
8
Load front
ink spindle
with an
empty take-
up core.
Pull ink from
rear to front
going under
the print
head and up
to the empty
take-up core.
Make sure
ink spindles
are as
shown.
NOTE:
Larger
circular end
on the left
side.
Close cover,
you're ready
to load Label
Media.
