VnM®4 Pro Templates: Pipe Marking
The Pipe Marking template meets ANSI/ASMI letter height standards and tape lengths,
allowing you to create custom pipe markers.
Below is a 2 x 12 pipe marker example identifying the contents of the pipe as NITROGEN (a).
NITROGEN
a) 2 x 12 inches
VnM Templates 4"
OSHA/ANSI Templates
GHS Templates
RTK Labels
Pipe Marking Templates
4" Marking Templates
Back
4" x 24" (1 Line)
4" x 32" (1 Line)
4" x X" (1 Line)
Repeat Wraparound Template
1. Enter your Text and press Enter when
ready to continue. Back
(Reference the Pipe Marker font on
Pg 21 for any available symbols)
2. Preview your sign or label and press
Enter if you are ready to print.
3. Enter the quantity of signs to print and
press Enter.
FIRE SPRINKLER WATER
b) 1 x 7 inches
DOMESTIC CHILLED WATER;
d) 3 x 24 inches
1. Select the
2. Scroll and select the preferred width of your
DIE CUT
DIE CUT
Select
Select
Copyright © 2020 Cobra Systems, Inc. All rights reserved
Pipe Markting Templates
pressing Enter on the keyboard.
pipe marker and press Enter to continue.
1" x 7" (1 Line)
4" Marking Templates
2" x 14" (1 Line)
3" x X" (1 Line)
4" x 24" (1 Line)
4" x 32"(1 Line)
4" x 32" (1 Line)
4" x X" (1 Line)
Repeat Wraparound Template
Back
1. Enter your Text or Symbol and press
Enter when ready to continue.
(Reference the Pipe Marker font on
Pg 21 for any available symbols)
2. Enter the inch diameter of your pipe
and press Enter to continue.
3. Preview your sign or label and press
Enter if you are ready to print.
4. Enter the quantity of signs to print and
press Enter.
€ € € € € €
c) 2 inch Repeat Template, 4 inch diameter
VnM4 Tips
IF YOU ARE NOT SURE WHICH
TEMPLATE TO USE, REFER TO THE
VNM PIPE MARKING GUIDE ON
PAGE 22.
by
2" x 12" (1 Line)
3" x 24" (1 Line)
4" x 24" (1 Line)
4" x X" (1 Line)
Select
