Mocka Essentials Large Bookcase Assembly Instructions Manual page 5

Mocka Essentials Large Bookcase
Jolt Wardrobe
Assembly Instructions
ASSEMBLY INSTRUCTIONS
7
Y
W
Attach 2x safety straps (W) to panel [1] using 2x r/washer screws (Y).
Tighten with a screwdriver.
mocka.co.nz | mocka.com.au mocka.co.nz | mocka.com.au
Y
W
1
8
B
A
C
A
B
2
B
B
C
A
Attach panel [1] to panels [6] and [12] using 4x dowels (C), 4x bolts (A)
and secure with 4x locking nuts (B). Attach panel [2] to panels [6] and
[12] using 4x dowels (C), 4x bolts (A) and secure with 4x locking nuts (B).
Tighten with a screwdriver.
A
C
A
B
6
1
B
A
C
A
B
12
5
5
