Mocka Essentials Large Bookcase Assembly Instructions Manual page 2

Mocka Essentials Large Bookcase
Assembly Instructions
1
3
x2
E
E
Separate the 2x stoppers (H) as shown and attach the bracket parts to
each panel [3] using 4x screws (E). Tighten with a screwdriver. Cover
each bracket with the clip parts. Tighten with a screwdriver.
mocka.co.nz | mocka.com.au
E E
H
E E
H
H
H
2
3
B
B
B
A
C
Attach panels [3] and [4] to panel [12] using 6x dowels (C), 6x bolts (A)
and secure with 6x locking nuts (B). Tighten with a screwdriver.
3
4
B
B
B
A
B
C
A
A
C
A
A
12
2
