Target fairglen Assembly Instruction Manual page 8

step 2: attach top panel, bottom panel, and shelf to left side panel
(H1) x 6 (H3) x 6
wooden dowel cam
2.1. Carefully tap small wooden dowels into place in left side panel. Leave 1/2" of the dowels sticking out. 2.1. Carefully tap small wooden dowels into place in left side panel. Leave 1/2" of the dowels sticking out.
2.2. Screw-In cam bolts must be screwed down flush in left side panel. 2.2. Screw-In cam bolts must be screwed down flush in left side panel.
2.3. Refer to page 6 for instructions on how to use the cam lock system. 2.3. Refer to page 6 for instructions on how to use the cam lock system.
2.4. Do not over tighten bolts. 2.4. Do not over tighten bolts.
8
finished edge
