Page 2
Congratulations on your latest Target purchase. Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you. All you need to do is follow our simple instructions and you’ll be on your way to transforming your room in no time.
Page 3
table of contents introduction hardware parts list how to use the cam lock system assembly 7-11 QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and dpci number ready when calling.
Page 4
hardware (H1) x 21 (H2) x 20 (H3) x 20 (H4) x 4 wooden dowel cam bolt flat head screw...
Page 5
exploded diagram ITEM DESCRIPTION QUANTITY top panel left side panel right side panel partition sliding door bottom panel support rail back panel...
Page 6
how to use the cam lock system Screw cam bolt into panel Align cam bolt(s) with cam(s) Push cam into panel - arrow feature and insert all the way into on cam top points to panel edge cross-bored hole(s) 4. 4. 5.
Page 7
step 1: attach top panel to back panel and partition (H1) x 7 (H2) x 4 (H3) x 4 (H4) x 4 wooden dowel cam bolt flat head screw 1.1. Carefully tap small wooden dowels into place in top panel. Leave 1/2” of the dowels sticking out. 1.2.
Page 8
step 2: attach bottom panel (H1) x 4 (H2) x 4 (H3) x 4 wooden dowel cam bolt 2.1. Carefully tap small wooden dowels into place in bottom panel. Leave 1/2” of the dowels sticking out. 2.2. Screw-In cam bolts must be screwed down flush in bottom panel. 2.3.
Page 9
step 3: install sliding door 3.1. Insert sliding door into tracks located on top panel and bottom panel.
Page 10
step 4: attach right side panel (H1) x 5 (H2) x 6 (H3) x 6 wooden dowel cam bolt 4.1. Carefully tap small wooden dowels into place in right side panel. Leave 1/2” of the dowels sticking out. 4.2. Screw-In cam bolts must be screwed down flush in right side panel. 4.3.
Page 11
step 5: attach left side panel (H1) x 5 (H2) x 6 (H3) x 6 wooden dowel cam bolt 5.1. Carefully tap small wooden dowels into place in left side panel. Leave 1/2” of the dowels sticking out. 5.2. Screw-In cam bolts must be screwed down flush in left side panel. 5.3.
Page 12
l b s adjustable leg levelers 1. This unit has been designed for the weight shown. Exceeding this recommended weight could result in excessive “sagging” of the top. Extreme overloading can cause failure of the top and possible injury. 2. Furniture Care Instructions: Dust with a clean, lint-free cloth. Use a spray furniture polish as needed. QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service.
