Target fairglen Assembly Instruction Manual page 10

step 4: assemble drawer box
(H1) x 2 (H2) x 4
wooden dowel cam bolt
4.1. Carefully tap small wooden dowels into place in drawer front. Leave 1/2" of the dowels sticking out.
4.2. Screw-In cam bolts must be screwed down flush in drawer front.
4.3. Refer to page 6 for instructions on how to use the cam lock system. Do not over tighten bolts.
4.4. Slide drawer bottom into drawer side panels and front.
4.5. Align flat head screws with pre-drilled holes to attach drawer back panel. Do not over tighten screws
10
(H3) x 4 (H4) x 4
cam flat head screw
