Cables: Your MEGA Live Imaging transducer comes with the cables required
to connect directly to your Humminbird fish finder. In addition to the cables
permanently attached to the transducer, this includes two extension cables (a 10'
MEGA Live power cable and a 20' Ethernet cable) to allow for quick-disconnect. To
connect the Ethernet to a HELIX control head, you will need to purchase an ethernet
adapter cable.
NOTE: An ethernet switch (separate purchase required) can be used to connect
your MEGA Live Imaging transducer to multiple control heads. To purchase accessories
for your control heads, visit our Web site at humminbird.com or contact Humminbird
Technical Support at 1-800-633-1468.
Accessories: Additional recommended accessories include a Humminbird
Heading Sensor GPS Puck (and a Heading Sensor GPS Adapter cable for APEX and
SOLIX only), or a Minn Kota Heading Sensor connected to an i-Pilot Link trolling
motor. For the most current list of compatible accessories, visit our Web site at
humminbird.com.
Supplies
In addition to the hardware included with your accessory, you will need the
following supplies:
• Cable ties for cable routing
• 2 Amp fuse
• Multi-bit screwdriver
Switch (optional): If you do not have a main switch or fuse panel available on your
boat to connect power, you will need to purchase a battery switch. See Install the
Trolling Motor Mount, Section 5: Route the Cables and Connect Power for more
information.
Introduction
2
