- Page 1 Solis Meter and CTs Installation Guide for SOL-RHI-3P(5-10K)-HVES-5G-DC...
- Page 2 Application Note Figure 1: Meter and CTs 1. Scope This document describes the application of the Solis Meter and CTs devices used with the inverter’s integrated export power control function for export power controlling. These two are a requirement for export control.
- Page 3 3. Typical System Installation Figure 2: Installation Setup 4. System Connection Wiring Diagram Figure 3: System Diagram...
- Page 4 5. Detailed Cable Connection The following figure illustrates how to connect the three-phase meter to a Solis High Voltage Inverter. To INV Backup output Figure 4: Detailed Cable Connection of Meter and CTs...
- Page 5 Step 1: The ports 5-6, 7-8 and 9-10 are the CT cable connections. Please ensure the CTs are connected with the correct polarity and the corresponding grid phase. Also, please note the small arrow inside the CTs, as shown in Figure 5, shall be pointed towards the Grid (5-6 to La, 7-8 to Lb, 9-10 to Lc) as shown in Figure 4.
