Control Panel

Channel Output On
button
Channel Select
button
Run.
The Run button is used to start and stop the signal generation. If the signal is being generated, the LED indicator
lights up. To output the signal through the output connectors, you must push the front-panel All Outputs On/Off button or
the Channel Output On button.
Touch Screen Off.
The LED is lit while the Touch Screen interface is disabled.
File Open/Save.
save a setup (*.AWG) file using this dialog box.
Factory Default.
setups.
Timing – Sampling Rate.
Sampling Rate is common to each channel. See page 26 for Settings window.
Channel Select.
the front panel is pushed, the selected channel page in the Settings Window will be activated.
Channel Output On.
LED is turned on.
CAUTION. Do not connect a DUT (Device Under Test) to the front-panel signal output connectors when the instrument
signal outputs are on.
Do not power on or off the DUT when the arbitrary waveform generator signal outputs are on.
AWG7000 Series Quick Start User Manual
Run button
When the Touch Screen is On state, you can use your finger or stylus to control the screen interface.
When the Open or Save button is pushed, the corresponding dialog box is displayed. You can load or
When this button is pushed, the specified default setups are recalled. See page 32 for details on default
When you push this button, the sampling rate parameter in the Settings window is selected.
These buttons are used to select a channel that you want to interact with. If a channel select button on
These buttons are used to enable/disable the channel output. If the output is in the On state, the
Control Panel
General Purpose knob
Digit Selection
keys
13
