Offline Mode

The Offline Mode is a function that you can use to run the instrument application on your PC. Install the application on your
PC; the instrument hardware is not required. You can create and edit the instrument setups. The setup files that you create
can be used later with your arbitrary waveform generator.
1. Use the Product Software CD provided
with the instrument to install the
AWG7000 series application to your
PC.
2. Before using the offline mode, you must
set up the instrument configuration.
From the Windows Start menu, select
All Programs > Tektronix > AWG >
Config Utility. The Configuration Utility
dialog box appears.
3. Select your instrument type.
4. Select your instrument option configura-
tion.
5. Click OK.
Run the instrument application from the
Start menu. The setup configuration
you have made using the Configuration
Utility will be reflected in the application.
