SRJ: speed adjust manually
During the operating process,as the manual speed already set,and we need to adjust the
current speed,and impossible to fix the value during it is working,then we can revise the SRJ
value to realize it.
Current manual speed FS#=Setting manual speed*SRJ.
F:Feedingspeed,the unit is mm/min.For example F=200,means every minute feeding
2000mm.
S: Spindle Speed. Unit is rad/min.For example S=20000,means 20000 revolution/Minute.
X axis Coordinate
Y axis Coordinate
Z axis Coordinate
A axis Coordinate
B axis Coordinate
C axis Coordinate
Ready:ReadyMode.In the mode we can do any operation,include processing or values
modification or starting 2nd mode.
Reset: Reset mode.In this mode,it should stop every operation.
"Step":Manual Step Mode. Every axis candonduct the manual step operation at this mode.
MPG: MPG mode.Every axis can conduct the MPG operation at this mode.
