Manual of NVEC400
4
OUT9
5
OUT11
6
GND
7
TXD2
8
GND2
9
OUT5
10
OUT7
11
GND
12
OUT10
13
OUT12
14
VCC5
15
RXD2
Table 2-1.
Output Port9
Output Port11
Ground for output
TXD for USART
Ground for USART
Output Port5
Output Port7
Ground for output
Output Port10
Output Port12
5V supply
RXD for USART
General output interface
- 11 -
www.nvcnc.net
definition
