GeoSnap PPK
DJI M210 Integration Guide
)
This integration guide is a resource for this specific integration and is meant to be referenced in conjunction
with the GeoSnap PPK Manual (https://fieldofviewllc.com/downloads/). If something is not mentioned in this
guide, then it is most likely discussed in the manual. If you have any questions regarding this manual, please
contact support by emailing
Revision date: November 4, 2020
support@fieldofviewllc.com
or calling +1 701-203-3757 ext. 3.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for dji GeoSnap PPK
Summary of Contents for dji GeoSnap PPK
- Page 1 This integration guide is a resource for this specific integration and is meant to be referenced in conjunction with the GeoSnap PPK Manual (https://fieldofviewllc.com/downloads/). If something is not mentioned in this guide, then it is most likely discussed in the manual. If you have any questions regarding this manual, please contact support by emailing support@fieldofviewllc.com...
-
Page 2: Table Of Contents
Installation ................................3 What’s in the Box ............................3 Installation Procedure ............................. 6 System operation ..............................16 Powering the GeoSnap PPK System ......................16 Battery Information ..........................16 Checking Battery Voltage ........................16 Battery Charging............................. 16 Purchasing Additional Batteries ......................17 Offsets ................................ -
Page 3: Installation
INSTALLATION WHAT’S IN THE BOX GeoSnap PPK and antenna installed on the DJI M210 mount Lower mount bracket for M210 Survey pole mount bracket 16 GB microSD card and microSD card adapter (the microSD card will be shipped installed in... - Page 4 Camera trigger cable (version provided will depend on version ordered) Hotshoe module (for DSLR style cameras, not included for other camera options) GeoSnap-to-hotshoe cable (version provided will depend on version ordered) PWM/GPIO input cable Field of View GeoSnap PPK Manual...
- Page 5 (use this if you want record events without a camera connected) Cable routing clips (4) Ziptie (1) Li-Po batteries (2 batteries total included) DC-4S charger/voltage checker AC charging cable (includes the international plugs shown) Field of View GeoSnap PPK Manual...
-
Page 6: Installation Procedure
MicaSense camera you can skip steps 2,3,6,7,8, and 9. If you are using a MicaSense camera please reference the integration guide specific to your camera found at www.fieldofviewllc.com/geosnap-ppk-downloads. 1. It is recommended to install the DJI Matrice 200 external GPS module so that the GPS system for the drone has a completely unobstructed view of the sky. - Page 7 2. Install the Micasense DLS 2 on the mount provided by Field of View. DSL2 cable connector 3. Install the DLS2 mount on the GeoSnap PPK plate. Field of View GeoSnap PPK Manual...
- Page 8 4. Secure the GeoSnap PPK lower mounting bracket using the 4 screws and included hex key to the top of the drone. Field of View GeoSnap PPK Manual...
- Page 9 5. Place the GeoSnap PPK on top of the lower mounting bracket. You must first insert the tab of the GeoSnap PPK into the front receptacle on the lower mounting bracket. Then press down and turn the two quarter-turn studs clockwise until a click is felt to lock the GeoSnap PPK in place. Lift up on the GeoSnap PPK to ensure it is locked in place.
- Page 10 7. Use the provided ziptie and adhesive ziptie mount to organize and secure the DLS 2 ribbon cable to the camera. 8. Plug in the last two connectors of the GeoSnap PPK-to-MicaSense cable into the PWR/TRG and DLS ports of the MicaSense RedEdge-MX.
- Page 11 Field of View GeoSnap PPK Manual...
- Page 12 9. Install the Micasense RedEdge-MX in the M210 Skyport as shown (the cable lengths are optimized for use in gimbal slot II). Field of View GeoSnap PPK Manual...
- Page 13 10. Attach a cable mounting clip in the location shown and route the DLS 2 ribbon cable through it. 11. Next, route the GeoSnap PPK-to-Micasense cable through the same cable clip and use zipties to secure the two cables just below and just above the cable routing clip to prevent the cables from sliding up or down.
- Page 14 12. Plug the DLS 2 ribbon cable into the DLS 2 and the GeoSnap PPK-to-Micasense RedEdge-MX cable into the 6-pin connector from the side of the GeoSnap PPK. Field of View GeoSnap PPK Manual...
- Page 15 13. When you’re ready to fly, plug in the red battery power connector on the GeoSnap PPK. Field of View GeoSnap PPK Manual...
-
Page 16: System Operation
(thus preventing damage to the battery). The advantage of using these batteries to power the GeoSnap PPK (as opposed to using power from the drone) is that the GeoSnap PPK can keep logging and maintain GPS lock, even if the drone’s batteries needs to be swapped when mapping large areas. -
Page 17: Purchasing Additional Batteries
Purchasing Additional Batteries Additional batteries, charger/voltage checkers, and AC adapters can be purchased directly via the links below: Battery: https://hobbyking.com/en_us/turnigy-9xr-safety-protected-2200mah-3s-1-5c-transmitter-pack.html DC-4S charger/voltage checker: https://hobbyking.com/en_us/hobbykingr-dc-4s-balance-charger-cell-checker- 30w-2s-4s.html AC Power Adapter: https://hobbyking.com/en_us/power-supply-12v-3a-interchangeable-plug-adapter- upgraded.html Field of View GeoSnap PPK Manual... -
Page 18: Offsets
Using this diagram as a guide, Field of View has already calculated offsets from the antenna to the skyports of the M210 when using the GeoSnap PPK with M210 integration kit. Bottom-center of SKYPORT II-to-antenna L1 phase center offset: X offset: -0.034 meters... -
Page 19: Specifications
SPECIFICATIONS GeoSnap PPK with M600 Pro integration kit System weight 648 grams Mounting Style Quarter-turn quick release Battery included 3 cell, 2.2 Ah Li-Po Battery life ≈ 6 hours Includes antenna, control module, hotshoe module, M210 mounting hardware, battery, and cabling Dependent on environmental factors, age of battery, and charge level. - Page 20 All dimensions are in millimeters Field of View GeoSnap PPK Manual...
