MATRICE 200 SERIES
M210/M210 RTK
User Manual
2018.11
V1.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MATRICE 200 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dji MATRICE 200 Series

Summary of Contents for dji MATRICE 200 Series

  • Page 1 MATRICE 200 SERIES M210/M210 RTK User Manual V1.4 2018.11...

  • Page 2: Using This Manual

    * For increased safety, the flight is restricted to a height of 30 m and distance of 50 m when not connected or logged into the app during flight, including DJI GO 4 and all apps compatible with DJI aircraft.

  • Page 3: Table Of Contents

    Contents Using this manual Legends Before Flight Watch the video tutorials Download the DJI GO 4 app Download the DJI Assistant 2 Product Profile Introduction Feature Highlights Assemble the Aircraft Preparing the Remote Controller Aircraft Diagram Remote Controller Diagram Aircraft...
  • Page 4 Appendix Specifications Aircraft Status Indicator Description Upgrading the Firmware Using the Zenmuse XT Gimbal and Camera Single Downward Gimbals Dual Downward Gimbals Mounting the Upward Gimbal and GPS Module Carrying Box Descriptions After-Sales Information © 2018 DJI All Rights Reserved.
  • Page 5 Product Profile This chapter describes the features of the Matrice 210/Matrice 210 RTK, shows how to assemble the aircraft, and contains diagrams of the aircraft and remote controller with component explanations. © 2018 DJI All Rights Reserved.

  • Page 6: Product Profile

    * The Zenmuse XT Gimbal Adapter is required when mounting the Zenmuse XT gimbal to the Matrice 200 series aircraft. Both DJI GO 4 and DJI Pilot support the Zenmuse X5S, X4S, and Z30. DJI Pilot is required if using the Zenmuse XT and XT 2.

  • Page 7: Assemble The Aircraft

    MATRICE 200 SERIES User Manual Assemble the Aircraft This manual uses the M210 RTK and Zenmuse Z30 as an example to demonstrate setup and usage. Unfolding the D-RTK Antennas For the M200 series, only mount the D-RTK antennas to the M210 RTK.
  • Page 8 MATRICE 200 SERIES User Manual Mounting the Gimbal and Camera Press the gimbal Align the white Rotate the gimbal detachment button and red dots and lock to the locked to remove the cover. insert the gimbal. position. Make sure to press down the gimbal detachment button when rotating the gimbal lock to remove the gimbal and camera.

  • Page 9: Preparing The Remote Controller

    MATRICE 200 SERIES User Manual Mounting the D-RTK Ground System For the M200 series, only mount the D-RTK Ground System to the M210 RTK. 1. Rotate the screws to secure the antenna bracket, and install the battery. 2. Rotate the clamp to secure the battery, and install the Datalink Pro antenna.
  • Page 10 MATRICE 200 SERIES User Manual Mounting the Datalink Pro Air System to the Remote Controller For the M200 series, only mount the Datalink Pro Air System to the M210 RTK remote controller. M2×8 M3×5 Remove the screws. Affix the Datalink Pro Air System...

  • Page 11: Aircraft Diagram

    MATRICE 200 SERIES User Manual Aircraft Diagram 16 17 18 19 Folded 1. FPV Camera 14. D-RTK Antennas** 2. Forward Vision System 15. USB Port 3. DJI Gimbal Connector v2.0 (DGC2.0) 16. Expansion Ports 4. Gimbal Detachment Button 17. RC/Aircraft Linking 5.

  • Page 12: Remote Controller Diagram

    [4] Micro USB Port Use a Micro USB cable to connect to the remote controller when in use, or to the PC to configure parameters via DJI Assistant 2. To update aircraft firmware, please use the USB OTG cable. [5] Headphone Jack [6] Light-sensitive Port Built-in light-sensitive sensor.
  • Page 13 Switch between P-mode, S-mode, and A-mode. [34] Handle Bar [35] USB Port Connection to mobile device for DJI GO 4 app if used a third party mobile device. [36] HDMI A Port HDMI A Port is for video output. [37] CAN Bus Used to connect external devices.
  • Page 14 Aircraft This section describes the features of the Flight Controller, Vision System, and the Intelligent Flight Battery.

  • Page 15: Aircraft

    The aircraft’s descent speed is significantly increased in S-mode (Sport). A minimum braking distance of 164 feet (50 meters) is required in windless conditions. Use the Flight Mode switch on the remote controller to select aircraft flight modes. © 2018 DJI All Rights Reserved.

  • Page 16: Flight Status Indicator

    (or nose) of the aircraft. Front and rear LEDs can be turned off in the DJI GO 4 app. The Aircraft Status Indicators communicate the system status of the flight controller. Refer to the table below for more information about the Aircraft Status Indicators.

  • Page 17: Vision System And Infrared Sensing System

    MATRICE 200 SERIES User Manual No GPS and Forward and Downward Slow yellow flashing Vision Systems Fast green flashing Braking Warning Fast yellow flashing Remote Controller Signal Lost Slow red flashing Low Battery Warning Fast red flashing Critical Low Battery Warning...
  • Page 18 MATRICE 200 SERIES User Manual Detection Range The detection range of the Vision System is depicted below. Note that the aircraft cannot sense and avoid obstacles that are not within the detection range. 60cm 40cm The aircraft cannot detect objects in low-light conditions. Please fly with caution.
  • Page 19 Calibration The Forward and Downward Vision System cameras are calibrated prior to delivery. However, these cameras are vulnerable to impact and will require occasional calibration via DJI Assistant 2. Calibration with the included Visual Calibration Plate. 1. Power on the Intelligent Flight Battery and toggle the USB Mode Switch left.
  • Page 20 MATRICE 200 SERIES User Manual Follow the steps below to use the Vision System: 1. Ensure the aircraft is in P-mode and place the aircraft on a flat surface. Note that the Vision System cannot work properly on surfaces without clear pattern variations.

  • Page 21: Return-To-Home (Rth)

    MATRICE 200 SERIES User Manual The performance of your Vision System and Infrared Sensing System is affected by the surface being flown over. Ultrasonic sensors may not be able to accurately measure distances when operating above sound-absorbing materials and the cameras may not function correctly in suboptimal environments.
  • Page 22 Smart RTH Use the RTH button on the remote controller or tap the RTH button in the DJI GO 4 app and follow the on-screen instructions when GPS is available to initiate Smart RTH. The aircraft will then automatically return to the last recorded Home Point. Use the remote controller to control the aircraft’s speed or altitude to avoid a collision during the Smart RTH process.
  • Page 23 MATRICE 200 SERIES User Manual Battery Aircraft Status Flight Level Remark DJI GO 4 App Indicator Instructions Warning Tap “Go-home” to have the aircraft return to the Home Fly the aircraft point and land automatically, back and land or “Cancel” to resume normal...
  • Page 24 Failsafe. The aircraft cannot avoid obstacles during Failsafe RTH if the Forward Vision System is disabled. It is important to set a suitable RTH Altitude before each flight. Launch DJI GO 4, enter camera and tap to set Failsafe Altitude.
  • Page 25 Users retain control of aircraft flight orientation. 3. If Landing Protection is inactive, the DJI GO 4 app will display a landing prompt when the aircraft descends below 0.7 meters. Tap to confirm or pull down the control stick for 2 seconds to land when the environment is appropriate for landing.

  • Page 26: Intelligent Flight Modes

    The aircraft supports Intelligent Flight Modes*, including TapFly, ActiveTrack, and Tripod Mode. Tap in DJI GO 4 or press the Function button on the remote controller to enable an Intelligent Flight Mode. * Intelligent Flight Modes are not supported to use with the dual downward gimbals.
  • Page 27 Be extra cautious when flying in too dark (< 300 lux) or too bright (>10,000 lux) environments. Enable control stick control of the gimbal inside DJI GO 4 to control gimbal orientation using the remote controller. When using the control sticks, the gimbal will automatically switch to Free mode.
  • Page 28 The aircraft automatically adjusts its speed when it senses an obstacle in front, or if it flies too close to the ground. The DJI GO 4 app will show a prompt if the aircraft flies over an obstacle or to the left or right of the obstacle.
  • Page 29 Use the roll stick on the remote controller or the remote control to circle the subject. The aircraft slider in DJI GO 4 to circle the subject. will not be able to avoid obstacles while in Profile Mode. Use this mode in open areas.
  • Page 30 Tap the icon in DJI GO 4 to enable Tripod Mode. Tripod Mode reduces the aircraft’s maximum speed (this can be adjusted in DJI GO 4 app), and the control stick sensitivity of the remote controller is dulled to give you the precision you need for accurate framing. Tripod Mode allow the aircraft to be used as a rocker arm or slide rail, shooting smoother, more stable footage.

  • Page 31: Flight Recorder

    10.0km/h 2.0m/s 2.0m You can drag on a subject in DJI GO 4 or move the gimbal control sticks to change the subject's position in the shot. Spotlight Pro can be used in S-mode, A-mode, TapFly and Tripod mode. Flight Recorder Flight data is automatically recorded to the internal storage of the aircraft.
  • Page 32 The Charging Hub will intelligently charge batteries in sequence according to battery power levels from high to low, if batteries are not paired. Pairing can be carried out using the DJI GO 4 app. The Micro USB port is used for firmware updates.
  • Page 33 Pairing can be carried out using the DJI GO 4 app. Refer to the "Status LED Description” section for more information about Status LED blinking patterns. The buzzer will begin beeping when charging is complete. Refer to the “Buzzer Beeping Description”...
  • Page 34 MATRICE 200 SERIES User Manual Always align the grooves on the Intelligent Flight Battery with the battery slot tracks. Press the release button to detach batteries after charging is complete. DO NOT leave metal terminals exposed to open air when not in use.
  • Page 35 1 hour Updating the Firmware DJI will release firmware updates when available. Refer to the official DJI website and follow the instructions below to update the firmware. 1. Download the latest firmware update program from the official DJI website.
  • Page 36 4.35 V before each flight. 2. End the flight as soon as DJI GO 4 displays the “Low Battery Level Warning” in low temperature environments. You will still be able to control the aircraft’s movement when this warning is triggered.

  • Page 37: D-Rtk And Datalink Pro

    2. Connect the aircraft to the computer and toggle the USB Mode Switch to the RTK position to activate the D-RTK air system. 3. Connect the D-RTK Ground System to the computer with DJI Assistant 2 launched for activation. ©...
  • Page 38 Press the Update button and hold for five seconds until the Ground System recalculates the position coordinates. The DJI GO 4 app will prompt you once the Ground System’s position has been updated successfully.
  • Page 39 1. Connect the Datalink Pro Ground System to the computer and move the 4-position switch to the COMBO position. 2. Launch DJI Assistant 2 and click the Datalink Pro icon to enter the Datalink Pro settings page. 3. Click M210 RTK Datalink Pro-Ground displayed on the Datalink Pro settings page and follow the prompts.

  • Page 40: Dji Airsense

    ADS-B outs. 2. If there is an obstacle or steel structure between civil and DJI aircraft, the system won’t be able to receive ADS-B messages sent by manned aircraft or send out warnings. Keenly observe your surroundings and fly with caution.

  • Page 41: Expansion Ports

    MATRICE 200 SERIES User Manual On the precondition that connection between a DJI aircraft and the pilot remote controller is stable, when the system confirms the possibility of a collision, it will send a series of warnings based on the distance between drone and manned aircraft. We recommended that the operator descend altitude immediately after the first warning to avoid a collision, choosing another flight path where necessary.
  • Page 42 MATRICE 200 SERIES User Manual Pins Descriptions PWM power level is 3.3V and all pins can be configured in DJI Pilot app. Number Name OSDK port I/O port I/O port I/O port I/O port I/O port SDK_Tx IO/PWM5 IO/PWM4 IO/PWM3...
  • Page 43 Remote Controller This section describes the features of the remote controller that includes aircraft and remote controller operations and dual remote controller mode.

  • Page 44: Remote Controller

    7.85 inch monitor, which offers an HD live camera view with its built-in DJI Pilot app or DJI GOTM 4 app for a precise and responsive flying experience. Dual transmission frequency support makes HD video downlink stable and reliable. In Dual Remote Controller mode, two remote controllers can control the aircraft and camera separately and simultaneously.
  • Page 45 MATRICE 200 SERIES User Manual Charging the Battery The remote controller is powered by a WB37 intelligent battery, which can be charged via the charging port or by the WCH2 Intelligent Battery Charging Hub. Using the Charging Port Place the battery into the remote controller, and connect connector B of the battery power port, then connect the battery charger to a power outlet (100-240V, 50/60Hz).

  • Page 46: Mounting The Monitor To The Remote Controller

    MATRICE 200 SERIES User Manual Mounting the Monitor to the Remote Controller Mounting the DJI CrystalSky Monitor Ensure that Part B is Lock the Mounting Bracket. Use a coin to adjust unlocked. Install Part B the tightness of the into Part A.

  • Page 47: Remote Controller Operations

    Users can use the preconfigured buttons to control the aircraft and the camera and can also assign functions to the customizable buttons through the DJI GO 4 app. There are three types of button: 1. Preconfigured buttons for aircraft control, e.g. the Pause Button, RTH Button, etc.
  • Page 48 MATRICE 200 SERIES User Manual Operating the Aircraft Controlling the Aircraft This section explains how to control the orientation of the aircraft through the remote controller. Control can be set to Mode 1, Mode 2 or Mode 3, or to a custom mode.
  • Page 49 MATRICE 200 SERIES User Manual Remote Controller Aircraft Remarks (Mode 2) Moving the left stick up and down changes the aircraft’s elevation. Left Stick Push the stick up to ascend and down to descend. When both sticks are centered, the aircraft will hover in place.
  • Page 50 The Flight Mode Switch is locked to P-mode, regardless of the Flight Mode Switch's position. To change flight modes, go to the Camera View in DJI GO 4 and enable Multiple Flight Modes in Main Controller Settings. After enabling multiple flight modes, toggle the switch to P for Position mode and S for Sport Mode.
  • Page 51 MATRICE 200 SERIES User Manual T h e r i g h t d i a l c o n t r o l s t h e gimbal pan. Turn the dial to the right, and the gimbal will shift clockwise.

  • Page 52: Dual Remote Controller Mode

    MATRICE 200 SERIES User Manual Configuring the Customizable Buttons Go to the Customizable Button Settings Menu in DJI GO 4. Here you can set functions for the left lever, right lever, C1-C4 buttons, and BA-BH buttons. Dual Remote Controller Mode More than one remote controller can connect to the same aircraft in Dual Remote Controller mode.
  • Page 53 Search Master When in Slave, the remote controller cannot link to the aircraft nor control aircraft orientation. Select Master in DJI GO 4 if you wish to connect and control the aircraft with the remote controller. 2. Search the “Master” remote controller in the surrounding area.

  • Page 54: Linking The Remote Controller

    3. Enter the Camera View and tap the Linking Remote Controller button shown below. 4. The DJI GO 4 app will display a countdown box, the remote controller will be ready to link, with its display showing Connecting and a beeping sound being emitted.
  • Page 55 MATRICE 200 SERIES User Manual A Slave remote controller cannot link to the aircraft and so therefore cannot control the orientation of the aircraft. Select Master in DJI GO 4 if you wish to link a remote controller it to the aircraft.
  • Page 56 Gimbal and Camera This section focuses on the technical specifications of the camera and explains how to use the gimbal.

  • Page 57: Gimbal And Camera

    Use the Shutter and Record buttons on the remote controller to shoot photos or videos. For more information on how to use these buttons, please refer to Controlling the Camera. DJI GO 4 Use DJI GO 4 to shoot photos or videos. For more information, refer to the camera and gimbal User Manual. ©...

  • Page 58: Gimbal

    +320° Using the DJI GO 4 App to Control Gimbal Follow the steps below to use the DJI GO 4 app to control gimbal orientation: 1. Launch DJI GO 4 and enter the Camera View. 2. Tap and press on the screen until a blue circle is shown.
  • Page 59 MATRICE 200 SERIES User Manual Gimbal Operation Modes Three gimbal operation modes are available. Switch between the different operation modes in DJI GO 4's Camera View. Note that your mobile device must be connected to the remote controller for changes to take effect. Refer to the table below for details:...

  • Page 60: Dji Go 4

    DJI GO 4 This section introduces the main functions of the DJI GO 4 app.

  • Page 61: Equipment

    Skypixel Both DJI GO 4 and DJI Pilot support the Zenmuse X5S, X4S, and Z30. DJI Pilot is required if using the Zenmuse XT and XT 2. This manual uses DJI GO 4 as an example. Please refer to the actual user interface.
  • Page 62 5. AirSense Status : AirSense Status displays information about nearby manned aircraft to ensure flight safety, including the distance between DJI aircraft and manned aircraft. AirSense will instruct users to land if nearby aircraft are detected. 6. GPS Signal Bars : Shows current GPS signal strength.
  • Page 63 MATRICE 200 SERIES User Manual 11. Battery Level : This icon shows current battery level. Tap to view the battery information menu, set various battery warning thresholds, and view battery warning history. 12. General Settings : Tap to enter the General Settings menu to set metrics to enable live streaming, display flight routes, and so on.
  • Page 64 MATRICE 200 SERIES User Manual 22. Flight Telemetry (1) Tap to switch to map view. (2) Flight Attitude and Radar Function: The red arrow shows which direction the aircraft is facing. The ratio of gray area to blue area indicates the aircraft’s pitch.

  • Page 65: Editor

    MATRICE 200 SERIES User Manual Editor A dedicated video editor is built into the DJI GO 4 app. After recording several video clips and downloading them to your mobile device, go to Editor on the home screen. You can then select a template and a specified number of clips that automatically combine, creating a short film for sharing.
  • Page 66 Flight This section describes safe flight practices and flight restrictions.

  • Page 67: Flight

    DJI GO 4 app. The locations designated by GEO are called GEO Zones. GEO Zones are specific flight areas that are categorized by flight regulations and restrictions. GEO Zones that prohibit flight are implemented around locations such as airports, power plants, and prisons.

  • Page 68: Flight Restrictions

    Restricted Zone, please go to https://www.dji.com/flysafe or contact flysafe@dji.com to unlock the zone. DJI GEO Zones aim to ensure the user’s flight safety, but it cannot be guaranteed to be in full compliance with local laws and regulations. Users should check local laws, regulations, and regulatory requirements before each flight and are responsible for the flight safety.
  • Page 69 MATRICE 200 SERIES User Manual Maximum Flight Altitude Max Radius Home Point Height of aircraft when turned on Strong GPS Signal Restriction Description DJI GO 4 App Message Aircraft's altitude cannot exceed Maximum Flight Altitude reached. Adjust Max Altitude the specified value.
  • Page 70 Altitude Zone. If it is higher than the altitude limit, the aircraft decelerates and hovers in place. When the GPS signal changes from weak to strong, DJI GO 4 app starts a 20-second countdown. Once the countdown is over, the aircraft will descend and hover below the altitude limit.

  • Page 71: Geo Unlocking

    7. Ensure that the sensors for the Obstacle Sensing System are clean. Calibrating the Compass Only calibrate the compass when the DJI GO 4 app or the status indicator prompts you to do so. Observe the following rules when calibrating your compass: DO NOT calibrate your compass where there is a chance of strong magnetic interference, such as near magnets, parking structures, or steel reinforcements underground.
  • Page 72 MATRICE 200 SERIES User Manual 3. Hold the aircraft vertically, with the nose pointing downward, and rotate it 360 degrees around the center axis. Re-calibrate the aircraft if the aircraft status indicators blink red. If the Aircraft Status Indicator blinks red and yellow after the calibration procedure, move your aircraft to a different location and try again.

  • Page 73: Auto Takeoff And Auto Landing

    If Landing Protection is not operational, the DJI GO 4 app will display a landing prompt when the aircraft descends below 0.7 meters. Pull down on the throttle or use the auto landing slider to land.

  • Page 74: Stop The Motor Mid-Flight

    Pull the left stick to the bottom right inside corner and press the RTH button at the same time. Only stop the motors mid-f light in emergency situations when doing so reduces the risk of damage or injury. Please check that CSC is activated inside DJI GO 4 app, then the user can stop the aircraft mid-air.
  • Page 75 Refer to the Disclaimer and Safety Guidelines for more information. IP43 Protection Rating Under stable laboratory conditions, the Matrice 200 Series achieves an IP43 protection rating by IEC60529 standards when equipped with standard TB50-M200 or TB55 Intelligent Flight Batteries. However, this protection rating is not permanent and may reduce over time after long-term use.
  • Page 76 Appendix...

  • Page 77: Appendix

    1760S Supported DJI Gimbals Zenmuse X4S/X5S/XT/Z30/XT 2 Single Downward Gimbal, Dual Downward Gimbals, Supported Gimbal Mounting Single Upward Gimbal Waterproof Level IP43 GNSS GPS+GLONASS Operating Temperature -4° to 113° F (-20° to 45° C) © 2018 DJI All Rights Reserved.
  • Page 78 MATRICE 200 SERIES User Manual Gimbal Angular Vibration Range ±0.01° Controllable Range Pitch: -130° to +40°; Roll: ±20°; Pan: ±320° Max Controllable Speed Pitch: 180°/s; Roll:180°/s; Pan:270°/s Interface Type DGC2.0 Mechanical Range Pitch: -140° to +50°; Roll: -50° to +90°; Pan: ±330°...
  • Page 79 MATRICE 200 SERIES User Manual Upward Infrared Sensing System Obstacle Sensing Range 0-16.4 feet (0-5 m) ±5° Operating Environment Large, diffuse and reflective obstacles (reflectivity >10%) Charger Model IN2C180 Voltage 26.1 V Rated Power 180 W Battery (TB50-M200) Name Intelligent Flight Battery Model TB50-4280mAh-22.8V...

  • Page 80: Aircraft Status Indicator Description

    DJI Assistant 2 or the DJI GO 4 app. For the Zenmuse Z30, XT and XT 2, only aircraft firmware can be updated via DJI Assistant 2 or the DJI GO 4 app. Gimbal firmware must be updated via a Micro SD card.

  • Page 81: Using The Zenmuse Xt Gimbal And Camera

    Method 1: Using the DJI GO 4 App Power on the remote controller and connect it with the DJI GO 4 app. A prompt will appear if a new firmware upgrade is available. To start upgrading, connect a mobile device to the Internet and follow the on-screen instructions.

  • Page 82: Single Downward Gimbals

    MATRICE 200 SERIES User Manual 2. Mount the Zenmuse XT onto the aircraft by securing the gimbal adapter. Single Downward Gimbals The dual downward gimbal connector is mounted onto the aircraft at the factory. To use the M210 or M201 RTK’s single downward gimbals it is necessary to first remove the dual downward gimbal connector and mount the single downward gimbal connector.
  • Page 83 MATRICE 200 SERIES User Manual 3. Disconnect the gimbal signal control cable and gimbal video cable from the dual downward gimbal connector. 4. Remove the three screws on the top of the single downward gimbal connector. 5. Connect the gimbal signal control cable and gimbal video cable to the single downward gimbal connector.

  • Page 84: Dual Downward Gimbals

    MATRICE 200 SERIES User Manual 7. Mount the single downward gimbal connector to the aircraft using the three damping balls. Dual Downward Gimbals A dual downward gimbal connector is required to use the M210 or M210 RTK’s dual downward gimbals.
  • Page 85 MATRICE 200 SERIES User Manual 4. Remove the four screws on the top of the dual downward gimbal connector. 5. Connect the gimbal signal control cable and gimbal video coaxial cable to the dual downward gimbal connector accordingly. Tighten the spring pad with screws to secure the gimbal video coaxial cable.
  • Page 86 Connector I and Gimbal Connector II cannot be mounted with two of the same Zenmuse gimbals. Gimbal Connector I's camera view will show on the main interface in the DJI Pilot app, while Gimbal Connector II's camera view will show on the assistant interface. You can switch between them.

  • Page 87: Mounting The Upward Gimbal And Gps Module

    MATRICE 200 SERIES User Manual Mounting the Upward Gimbal and GPS Module The built-in compass and GPS will fail to work if a single upward gimbal is in use. And the D-RTK antennas cannot receive the GPS signal when the aircraft is flying under a bridge or other tall buildings.
  • Page 88 MATRICE 200 SERIES User Manual DO NOT try to remove the GPS antenna without first removing the four screws that hold it in place as doing so could damage the antenna. Follow the steps below to mount the Upward Gimbal and GPS Module on the M210:...

  • Page 89: Carrying Box Descriptions

    MATRICE 200 SERIES User Manual Carrying Box Descriptions 1. Landing gear ×2 2. Propeller pair ×4 1. Aircraft 2. Remote controller 3. CrystalSky monitor/iPAD 4. Intelligent flight battery 5. WB37 intelligent flight battery 6. IN2CH charging hub 7. WCH2 charging hub 8.
  • Page 90 This content is subject to change. Download the latest version from http://www.dji.com/matrice-200-series If you have any questions about this document, please contact DJI by sending a message to DocSupport@dji.com. © 2018 DJI All Rights Reserved.
