IWAKI PUMPS MX-F250 Instruction Manual

Magnetic drive pump

Advertisement

Quick Links

IWAKI Magnetic Drive Pump
MX-F250/-F403 (Asia Edition)
Instruction Manual
Read this manual before use of product

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX-F250 and is the answer not in the manual?

Questions and answers

Summary of Contents for IWAKI PUMPS MX-F250

  • Page 1 IWAKI Magnetic Drive Pump MX-F250/-F403 (Asia Edition) Instruction Manual Read this manual before use of product...
  • Page 2: Table Of Contents

    Thank you for selecting an Iwaki MX-F Series Magnetic Drive Pump. This instruction manual deals with "Safety instructions", "Outline", "Installation", "Operation" and "Maintenance" sections. Please read through this manual carefully to ensure the optimum performance, safety and service of your pump. Contents Important instructions ························································...
  • Page 3: Important Instructions

    Important instructions For the Safe and Correct Handling of the Pump ● "Safety Instruction" section deals with important details about handling of the product. Before use, read this section carefully for the prevention of personal injury or property damage. ● Observe the instructions accompanied with "WARNING" or "CAUTION" in this manual. These instructions are very important for protecting users from dangerous situations.
  • Page 4: Safety Instructions

    Safety instructions WARNING ● Turn off power before work Be sure to turn off power to stop the pump and related devices before work. Make sure no one turns on power by mistake while working on the pump, otherwise it may result in a serious accident. If your working area is noisy or Turning off power dark, let other people know about the situation by displaying a notice such as "POWER OFF (Maintenance)"...
  • Page 5 Safety instructions CAUTION ● Restriction on pump operator The pump must be handled or operated by a qualified person with a full understanding of the pump. Prohibited ● For a specified application only Use of the pump in any application other than those clearly specified may result in personal injury or property damage.
  • Page 6 Safety instructions CAUTION ● Earthing Risk of electrical shock. Do not run the pump without earthing. Secure earth protection to reduce the risk. Grounding ● Install an earth leakage breaker Risk of electrical shock. Do not run the pump without a leakage breaker. Secure a leakage breaker to reduce the risk.
  • Page 7: Outline

    Outline 1. Unpacking & Inspection ......6 2. Product outline ........6 3. Model code ........... 7 4. Specification ......... 8 5. Dimension ..........8 6. Part names ........... 9 7. Overview ..........12 - 5 -...
  • Page 8: Unpacking & Inspection

    Outline 1. Unpacking & Inspection On unpacking the product, check the following points. If you find any problems, contact your nearest dis- tributor. 1. Check the information on nameplate (model code, flow rate, head and voltage) to see if the product is delivered as per order.
  • Page 9: Model Code

    Z : Specific gravity limit 1.8-2.0 e. Motors No code: Totally-enclosed-fan-cooled motor for indoor use Totally-enclosed-fan-cooled motor for outdoor use Increased safety motor f. Motor power voltage MX-F250/-F251/-F400/-F401 MX-F402/-F403 (3-phase standard motor) (3-phase IEC motor) 2: 200/220V 2: 200/220V 4: 380/400/415V (50Hz) or 440V (60Hz)
  • Page 10: Specification

    MX-F401V/Y 0.75kW MX-F401W/Z 1.8-2.0 MX-F402T/X MX-F402V/Y 1.5kW MX-F402W/Z 1.8-2.0 50×40 MX-F403T/X MX-F403V/Y 2.2kW MX-F403W/Z 1.8-2.0 ■ Pump weight Model MX-F250/-F400 MX-F251/-F401 MX-F402 MX-F403 MX-F 14.5kg 19.5kg 31.5kg 34kg MX-F (IE3) 22kg 38kg 43kg 5. Dimension Model MX-F250 MX-F251 MX-F251 (IE3)
  • Page 11: Part Names

    Outline 6. Part names MX-F250/-F251 & /-F401 MX-F250 MX-F251 MX-F401 Names Q'ty Materials Remarks Materials Remarks Materials Remarks Front casing CFRETFE CFRETFE CFRETFE Rear casing CFRETFE CFRETFE CFRETFE Impeller CFRETFE CFRETFE CFRETFE Ferrite mag. Ferrite mag. Ferrite mag. Drive magnet unit...
  • Page 12 Outline MX-F400 Materials Remarks Names Q'ty Materials Remarks No. Names Q'ty 1 Front casing 1 CFRETFE Alumina ceramics Liner ring 99.5% 2 Rear casing 1 CFRETFE Impeller CFRETFE 19 Rear thrust CFRETFE Alumina ceramics Spindle Drive mag- 1 Ferrite magnet 99.5% net unit +aluminum alloy...
  • Page 13 Outline MX-F402/-F403 Materials Remarks Names Q'ty Materials Remarks No. Names Q'ty 1 Front casing 1 CFRETFE Alumina ceramics Liner ring 99.5% 2 Rear casing 1 CFRETFE Impeller CFRETFE 19 Rear thrust CFRPFA Rear earth Drive mag- Alumina ceramics magnet Spindle net unit 99.5% +FCD450...
  • Page 14: Overview

    Outline 7. Overview Motor nameplate Pump unit Apply the power voltage specified on Not capable of self-priming. Prime the pump the nameplate. via inlet or outlet before operation. ( Follow an applicable local power regu- lation.) "Arrow" label Outlet The arrow indicates a rota- tional direction of the motor.
  • Page 15 Installation 1. Before installation ....... 14 2. Installation/Pipework/Wiring ....16 - 13 -...
  • Page 16: Before Installation

    Installation CAUTION ● Do not run pump dry Do not run pump dry (operation without priming water or with a suction valve closed). Otherwise, internal parts are excessively worn by friction heat and fatal pump damage results. * If the pump runs dry by mistake, turn off power and leave it for more than Prohibit one hour to cool it down.
  • Page 17 The MX-F is not self-priming pump. Prime the pump every time the pump is operated. Do not run pump dry (operation without liquid.), or internal parts seizing or excessive wear results. ■ Maximum operating pressure Do not allow a discharge pressure to exceed the limits below. Model MX-F250 MX-F251 MX-F400 MX-F401 MX-F402/-F403 Pressrue limits (MPa) 0.25...
  • Page 18: Installation/ Pipework/ Wiring

    Installation 2. Installation/ Pipework/ Wiring Upon becoming aware of danger or abnormality during operation, terminate work immediately and inspect/solve problems. WARNING ● Turn off power before work Be sure to turn off power to stop the pump and related devices before work. Make sure no one turns on power by mistake while working on the pump, otherwise it may result in a serious accident.
  • Page 19 Installation ■ Installation Arrange pump and pipework based on the following piping layout for a long period of operation. 1. Discharge pipe ( Support pipework to keep the pump free of piping weigh.) 2. Gate valve 3. Check valve 4. Pressure gauge 5.
  • Page 20 Tighten bolts diagonally at even torque. Model Bolt size Tightening torque MX-F250/-F251/-F400/-F401/-F402/-F403 20N•m ■ Piping load and momentum Try not to apply a heavy load to the inlet and outlet flanges. Permissible piping weight and moment to the pump are as below.
  • Page 21 Installation Permissible stress to outlet flange Permissible stress to inlet flange Pipe dia. (mm) Pipe dia. (mm) 40, 50 Load Load Load direction Load direction 0.10 0.15 0.10 0.10 0.10 0.15 0.15 0.20 Fy: compression 0.10 0.10 0.10 0.15 Fy: tension 0.10 0.15 Permissible moment to outlet flange...
  • Page 22 Installation 7. In flooded suction, install a gate valve on a suction line for easier overhaul & inspection. Keep this valve open at any time during operation. 8. Install a flushing line for cleaning the pump after handling a harmful liquid. 9.
  • Page 23 Installation ■ Discharge line 1. Support discharge piping so as not to directory weigh on the pump. 2. Lay a priming line when the pump is not under a flooded suction system. 3. Pipe resistance rises too high to obtain an intended flow if a discharge pipe I.D. is too long. Always take account of the increment of pipe resistance.
  • Page 24 Operation 1. Operational precautions ...... 23 2. Before operation ......... 24 3. Operation ..........24 - 22 -...
  • Page 25: Operational Precautions

    Caution ● The surface temperature of the pump or pipe rises high along with liquid temperature in or right after operation. Take preventive measures. Model Liquid temperatuer Surface temperature (at ambent 40°C) MX-F250/-F251/-F400/-F401/-F402/-F403 80°C 80°C 危 険 ● Noise level Model...
  • Page 26: Before Operation

    Operation 2. Before operation Take the next steps to start the pump at the first operation or after a long period of storage. 1. Clean the inside of piping and a supply tank. 2. Retighten flange fixing bolts and base fixing bolts. 3.
  • Page 27 Remarks Do not operate the pump below the minimum discharge capacity. ►The minimum discharge capacity: 10 /min (MX-F250/-F251/-F400/-F401), 20 /min (MX-F402/-F403) • Observe the minimum discharge capacity for the prevention of continuous closed-discharge operation. This rule holds true to not only manual operation but also automatic operation.
  • Page 28 Maintenance 1. Troubleshooting ........27 2. Maintenance & Inspection....28 3. Spare & Wear parts ......31 4. Dismantlement & Assembly ....32 - 26 -...
  • Page 29: Maintenance 1. Troubleshooting

    Maintenance 1. Troubleshooting If you can not find out the root cause of failure, contact us. Symptom Point to be checked Troubles Cause & When a discharge When a discharge Countermeasures valve is closed. valve is opened. The readings of pres- •...
  • Page 30: Maintenance & Inspection

    Maintenance 2. Maintenance & Inspection WARNING ● Access limitation The magnet drive pump has a pair of strong magnets. The strong magnet field could adversely affect the persons who are assisted by electronic devices Prohibited such as the pacemaker. ● Turn off power during maintenance work Risk of electrical shock.
  • Page 31 Maintenance ■ Periodic inspection To ensure efficient and smooth operation, perform periodic inspection. Be careful not to damage internal sliding parts and plastic parts when dismantling the pump. The magnetic force of a drive and a driven magnet is strong. Be careful not to catch the finger. Do not put electrical devices such as a watch and a mag card close to those magnets.
  • Page 32: Spare & Wear Parts

    Maintenance ■ Wear limits of bearing and spindle Check wear degree of the bearing and spindle. MX-F250/-F251/-F400/-F401 MX-F402/-F403 Model Before use Wear limit Before use Wear limit Bearing inner diameter Spindle outer diameter 1. Above values show wear limit of the bearing and spindle.
  • Page 33: Spare & Wear Parts

    Maintenance ■ Spare parts list Part name MX-F250 MX-F251 MX-F400 MX-F401 MX-F402 MX-F403 MX0417 MX0429 MX0436 MX0811 1 Front casing unit MX0418 MX0430 MX0437 MX0812 2 Rear casing MX0419 MX0431 MX0438 MX0815 MX0420 MX0831 MX0432 MX0439 MX0449 MX0458 29 Impeller unit T 50Hz...
  • Page 34: Dismantlement & Assembly

    Maintenance 4. Dismantlement & Assembly WARNING ● Access limitation The magnet drive pump has a pair of strong magnets. The strong magnet field could adversely affect the persons who are assisted by electronic devices Prohibited such as the pacemaker. ● Turn off power during maintenance work Risk of electrical shock.
  • Page 35 3. Detach the impeller unit from the magnet capsule unit as necessary. Be careful not to damage the units. a. MX-F250/-F251/-F400/-F401 Slightly tap the back of the impeller unit by a plas- tic hammer while holding the magnet capsule unit.
  • Page 36 Maintenance b. MX-F402/-F403 Turn two lock pins 90 degrees anticlockwise using a flathead screwdriver and then push them off inwards. If it is hard to do so, slightly tap the end of Lock pin driver handle. The lock pins can also be turned by using a 4mm hex.
  • Page 37 Maintenance ■ Assembly 1. Mount the impeller unit to the magnet capsule unit. Through-hole a. MX-F250/-F251/-F400/-F401 U-shape hole Slide the impeller unit down into the magnet cap- sule unit as far as it will go, locating the U-shape holes under the through holes.
  • Page 38 Maintenance Lock pin After fitting the impeller unit, insert two lock pins all the way seated in the lock pin holes from an inner surface. Use a flathead screwdriver to turn the pins 90 degrees clockwise from the outside while holding the pins from the inside.
  • Page 39 (except the F400). Note that the F402 and F403 have two pairs of them. 5. Fasten the front casing to the motor bracket. Tighten the hex. socket bolts evenly. Tightening torque is shown below. Model Tightening torque MX-F250/-F251/-F400/-F401 11.8N•m MX-F402/-F403 14.7N•m - 37 -...
