SubDrive/MonoDrive Connect
SubDrive15, SubDrive20, SubDrive30, MonoDrive, MonoDriveXT
Fan Replacement Install Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the SubDrive15 Connect and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Franklin Electric SubDrive15 Connect

  • Page 1 SubDrive/MonoDrive Connect SubDrive15, SubDrive20, SubDrive30, MonoDrive, MonoDriveXT Fan Replacement Install Guide...
  • Page 2 - Verify that the fan runs for 3–5 seconds during the power-up initialization. If the fan does not perform as stated above, note the error and consult your local Franklin Electric representative or call the Franklin Electric Technical Service Hotline at 1-800-348-2420.
  • Page 3 SUBDRIVE/MONODRIVE CONNECT FAN REPLACEMENT INSTALL GUIDE WARNING REMOVE ALL INCOMING ELECTRICAL POWER TO THE DRIVE. THIS IS A NON-POWERED ELECTRIC PROCEDURE. STEP 1: Verify the fan replacement kit. SubDrive/MonoDrive Size Fan Kit No. Fan Cover SubDrive15 and MonoDrive 80 mm (3.15”) 226545904 Integrated SubDrive20/30 and MonoDriveXT...
  • Page 4 SUBDRIVE/MONODRIVE CONNECT FAN REPLACEMENT INSTALL GUIDE STEP 3: Disconnect the power connection from the main board. STEP 4: Remove the fan from the enclosure. STEP 5: Locate the airflow indication arrow on the side of the fan. Position the fan so that the air is directed into the enclosure. MonoDrive and SubDrive15 MonoDriveXT and SubDrive20/30...
  • Page 5 SUBDRIVE/MONODRIVE CONNECT FAN REPLACEMENT INSTALL GUIDE STEP 6: Install the replacement fan into the enclosure. STEP 7: While holding the fan in place with one hand, secure it to the enclosure using the supplied plastic rivets. To install the rivet, first insert the outer plug and then insert the plunger to secure.
  • Page 6 STEP 9: Fan installation is complete. Verify that fan turns on and is working properly. If you experience any difficulty in performing these steps, consult your local Franklin Electric representative or call the Franklin Electric Technical Service Hotline at 1-800-348-2420.
  • Page 8 TOLL-FREE HELP FROM A FRIEND Franklin Electric Technical Service Hotline 800-348-2420 9255 Coverdale Rd., Fort Wayne, Indiana 46809 226546102 Tel: 260-824-2900 • Fax: 260-824-2909 Rev. 0 franklinwater.com 05-16...
