Oontz Angle 3 Quick Start Manual
Portable bluetooth speaker dual speaker model
Hide thumbs
Also See for Angle 3:
- Quick start manual ,
- Manual (11 pages) ,
- Quick start manual (28 pages)
Subscribe to Our Youtube Channel
Related Manuals for Oontz Angle 3
Summary of Contents for Oontz Angle 3
- Page 1 Quick Start Guide Portable Bluetooth Speaker OontZ Dual Speaker Model Designed and Engineered By Lastest version of TheOontZ.com Quick Start Guide available online at www.theoontz.com/support...
-
Page 2: Table Of Contents
To Play with Non-Bluetooth Audio Source Devices Use the 3.5mm Audio Cable IPX5 Water Resistance Wireless Hands Free Personal Speakerphone OontZ Dual Speaker - Connect Two OontZ Angle 3 Speakers Together 17 - 21 Resetting Your OontZ Angle 3 Troubleshooting & Customer Support... -
Page 3: In The Package
In the Package Quick-Start Guide USB Type C Charging Cable Note: The USB Type C Charging Cable is packed below the cardboard insert at the end of the triangle box. Slide out the insert to locate the cable. Page 1... -
Page 4: Buttons
Down for 2 Seconds Important - Make sure the volume level is set high on your audio source device. The volume on the OontZ Angle 3 and your audio source device both need to be set to the highest level for the loudest volume. The volume controls on your audio source device and the speaker work independently of each other. -
Page 5: Lights
AUX IN Jack Lit White/Orange when the speaker is the second speaker connected in OontZ Dual Speaker - With a second OontZ Angle 3 speaker (sold separately) you can wirelessly connect both speakers together to play with OontZ Dual Speaker. -
Page 6: Connectors
Connectors Built-in Mic for Speakerphone AUX IN Jack USB Type C - covers connectors to be closed to keep the - pull gently from the bottom to access speaker water resistant water resistance Page 4... -
Page 7: Play Horizontally Or Vertically
Play Horizontally or Vertically Play Horizontally Play Vertically Controls on side Controls on top Dual Precision Stereo Drivers – Has its own grille – Faces bass away from Dual Precision Stereo Drivers – Rich bass does not interfere with Mids and Highs Page 5... -
Page 8: Battery Features
- You can play while charging. 15 minutes of not playing audio to conserve the battery charge. * - When plugged into a charging source the OontZ Angle 3 will remain on - When the battery charge has less than 15%... -
Page 9: Charging The Battery
Charging the Battery - Insert the small end of the USB Type C Charging Cable into the USB Type C Charging Connector as Lit Red when charging: shown. - Insert the larger end of the USB battery is charging Type C Charging cable into a USB wall charger for a Smartphone or iPhone, or a USB port on your battery is fully charged... - Page 10 Insert the larger end of the USB Type C Charging Cable into a USB wall charger for a Smartphone or iPhone (USB wall charger* that is 5V 3.0A maximum), or a USB port on your laptop/computer to charge the OontZ Angle 3 battery. Only use a USB wall charger that is UL listed. A USB wall charger will have the logo printed on it.
- Page 11 Turn ON Press and Release the Power Button The speaker is turned on and is in pairing mode - Solid Blue The speaker is turned on and has connected to an audio source device and is ready to play Turn OFF Press and Hold Down the Power Button for 2 Seconds Page 9...
- Page 12 Pair & Connect -- Step 1 - Your device needs to be within 100 unobstructed feet of the OontZ Angle 3 to pair and connect. If there is an issue when connecting please move your device closer to the speaker, then pair and connect.
- Page 13 - Go to Settings > Bluetooth, check Bluetooth is on - Select 'OontZ Angle 3 TWS xxx' when it appears under DEVICES (xxx: 3 characters which are unique to your speaker) - Your device will connect in a few seconds...
-
Page 14: Pair & Connect -- Step 2
- Select the 'OontZ Angle 3 TWS xxx' (xxx: 3 characters unique to your speaker) when it appears - The OontZ Angle 3 will make a 'ding' sound when connected To connect the next time, turn on the OontZ Angle 3 and say "Alexa, connect my speaker" or "Alexa, pair" Page 12... -
Page 15: From Your Amazon Echo Device
It can remain on and available to play from the Amazon Echo device. - Or - - When you want to connect and play to the speaker again turn on the OontZ Angle 3 and say "Alexa, connect my speaker" or "Alexa, pair". -
Page 16: To Play With Non-Bluetooth Audio Source Devices Use The 3.5Mm Audio Cable
- You are now ready to play. Important: The Bluetooth on the OontZ Angle 3 is disabled when a 3.5mm audio cable is connected to the speaker. You need to remove the 3.5mm audio cable from the speaker in order to connect to a Bluetooth device. -
Page 17: Ipx5 Water Resistance
IPX5 rating - The OontZ Angle 3 can resist gentle water spray & splash but cannot be partially or fully submerged or left in a wet environment for an extended period of time, any of which could cause unrepairable damage to the speaker. -
Page 18: Wireless Hands Free Personal Speakerphone
Wireless Hands Free Personal Speakerphone - The Wireless Hands Free Personal Speakerphone feature works over Bluetooth with Smartphones and iPhones only or other types of devices. - Press and Release the Bluetooth Button - Press and Hold Down the Bluetooth Button for 3 Seconds. - Page 19 OontZ Dual Speaker - Connect two OontZ Angle 3 Speakers Together Bluetooth for playing music for stereo separation Right Channel Left Channel Bluetooth Dual Mode for playing music In separate areas Dual Dual *Placing the speakers on the ground or having walls or obstructions between the...
- Page 20 - After a few seconds the Play Control Speaker will say “Left Channel” and the second speaker will say “Right Channel”. The Play Control Speaker speaker light will remain solid Blue and the second speaker light will be solid White. The OontZ Angle 3 speakers will be connected together for Left Channel - Right Channel and you are ready to play.
- Page 21 Two OontZ Angle 3 Speakers connected for Left Channel - Right Channel Play Control Speaker Second Speaker Lit White Lit Blue – Use the buttons on the Play Control Speaker for play/pause, track back, track forward, answer and end phone calls. These controls are disabled on the second speaker when paired together.
- Page 22 Changing to Dual Mode from Left Channel - Right Channel – With the speakers connected together for , you can change the speakers to Dual Mode. – To change to Dual Mode, quickly press the twice on the Play Control Speaker. The second speaker light will turn from solid White to solid Orange.
- Page 23 – It is not recommended to play the audio from a video with two OontZ Angle 3 speakers connected in OontZ Dual Speaker. Playing the audio from a video or TV in OontZ Dual Speaker will have a delay in the audio playback from a video and will cause the audio and video to play out of sync with each other.
-
Page 24: Resetting Your Oontz Angle 3
Resetting Your OontZ Angle 3 Remove the Micro USB charging cable and 3.5mm Audio cable, if connected. Step 2: Press and hold down the together for 1 second, then release. The speaker has now been reset and you can turn it on. - Page 25 For issues with your OontZ Angle 3, please view our troubleshooting tips at: and select the OontZ Angle 3 Dual Speaker Customer Support If you have any issues with your OontZ Angle 3, our Customer Support Team wants to assist you. TheOontZ.com/support Please contact us at:...
-
Page 26: Safety And Precautions
Safety and Precautions Read and follow all instructions – All operating and use instructions should be followed. Protect the USB Type C Charging Cable from being pinched, particularly at the connectors. Unplug the USB Type C Charging Cable during lightning storms or when unused for long periods of time. Do not place speaker near any heat sources such as radiators, heat registers, stoves, or other apparatus (including Do not make alterations to this speaker. - Page 27 Safety and Precautions (continued) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 29 OontZ Angle 3 BudZ OontZ True Wireless BudZ OontZ Angle 3 Carry Case Sold separately Sold separately Sold separately • Superior Sound and Deep Bass • Amazing Sound and Rich Bass • Lightweight neoprene rubber with reinforced zipper • Waterproof and Sweatproof •...
