Summary of Contents for Oontz ANGLE 3
- Page 1 Ultra-Portable Bluetooth Speaker Quick Start Guide Designed and Engineered By Please visit TheOontZ.com...
-
Page 2: Table Of Contents
Pairing & Connecting -- From Your Apple Mac or Windows Computer Playing From Your Laptop, Computer and Non-Bluetooth Devices Using the 3.5mm Audio Cable IPX5 Water Resistance Wireless Hands Free Personal Speakerphone Troubleshooting & Customer Support 11 - 13 Resetting Your OontZ Angle 3 Safety and Precautions... -
Page 3: In The Package
In the Package USB Micro Charging Cable 3.5mm Audio Cable OontZ Angle 3 Speaker Quick-Start Guide Page 1... -
Page 4: Buttons And Connectors
Buttons and Connectors Charging LED Light (Red) (LED visible when connected to a Built-in Mic for Speakerphone charging source) Power Button Bluetooth LED Light (Blue) (LED is only visible when speaker is turned on) Rubber Flap (lifts up from bottom) Bluetooth Button AUX IN Jack (Dual-Function) -
Page 5: Charging The Battery
The lithium ion rechargeable battery will have a partial Charging the Battery charge and be ready to play. For maximum playtime, fully charge the battery. You can play while charging. To charge the battery: Step 1: Lift up the rubber flap from the bottom to Charging LED access the Micro USB Charging Port. -
Page 6: Charging The Battery
15% the Charging LED Light (Red) Play while charging will begin flashing Red You can play the OontZ Angle 3 while it is charging. and will remain flashing until the speaker is turned Power Saving Feature off. -
Page 7: Turning On And Off
Turning On and Off Turn ON Press and Release the Power Button Bluetooth LED Light (Blue) Blue light will turn on Flashing Blue indicates speaker is in Bluetooth LED pairing mode Light (Blue) Solid Blue indicates speaker is connected to a source device and ready to play Turn OFF Press and Hold Down the Power Button for 3 Seconds... -
Page 8: Pairing & Connecting
If the blue light is solid the OontZ Angle 3 has automatically reconnected to the last source device the speaker was connected to and is ready to play. Note: The OontZ Angle 3 will automatically try to connect to the last source device it was connected to each time it is turned on and that source device is within range. -
Page 9: Pairing & Connecting -- From Your Mobile Device
- The speaker will connect in a few seconds - The Bluetooth LED Light (Blue) will be solid blue - You can now play your audio wirelessly to your OontZ Angle 3 - You can now play your audio wirelessly to your OontZ Angle 3 Note: Your Smartphone or Tablet instructions may vary, please check your mobile device’s manual for specific pairing instructions... -
Page 10: Playing From Your Laptop, Computer And Non-Bluetooth Devices Using The 3.5Mm Audio Cable
You are now ready to play. - Note: The Bluetooth on the OontZ Angle 3 is disabled when the 3.5mm audio cable is connected to the speaker. You need to remove the 3.5mm audio cable from the speaker in order to connect to a Bluetooth source device. -
Page 11: Ipx5 Water Resistance
IPX5 rating - The OontZ Angle 3 can resist gentle water spray & splash but cannot be partially or fully submerged or left in a wet environment for an extended period of time, any of which could cause unrepairable damage to the speaker. -
Page 12: Wireless Hands Free Personal Speakerphone
Wireless Hands Free Personal Speakerphone To answer an Incoming Call / To End a Call Press and Release the Bluetooth Button Bluetooth Button To Reject an Incoming Call (Dual Function) Press and Hold Down the Bluetooth Button for 3 Seconds The Wireless Hands Free Personal Speakerphone feature works over Bluetooth with Smartphones and iPhones for cell phone calls only. -
Page 13: Troubleshooting & Customer Support
• Your source device may be out of range. Move it closer to within 30 unobstructed feet of your speaker. • Check the Bluetooth LED light (Blue) to make sure it is flashing. If it is solid blue the OontZ Angle 3 is already connected to another source device. - Page 14 For iPhone, iPad, iPod • Turn off the OontZ Angle 3 speaker, go to the Bluetooth device list on your iPhone, iPad or iPod and check if the OontZ Angle is listed. If it listed press the icon next to the OontZ Angle and then forget this device, twice.
- Page 15 • Reset the OontZ Angle 3, follow the reset instructions on page 14. • Remove the OontZ Angle 3 from the Bluetooth device list on your source device, restart your source device, and then re-pair and connect to the speaker.
-
Page 16: Resetting Your Oontz Angle 3
Resetting Your OontZ Angle 3 To reset the OontZ Angle 3 insert either a toothpick or straightened paper clip into the AUX IN jack until it makes contact with the micro switch. Gently push and release the switch and the speaker will reset. -
Page 17: Safety And Precautions
Safety and Precautions 1. Follow all instructions – All operating and use instructions should be followed. 2. Do not use this apparatus near water while plugged in for charging, due to risk of electric shock. 3. Protect the Micro USB charging cable from pinched particularly at the connectors. 4. - Page 18 OontZ Angle 3 Carry Case Sold separately • Lightweight neoprene rubber with reinforced zipper • Includes a durable aluminum carabiner for easily attaching to backpacks, luggage, laptop bags, coolers, camera bags, purses, belts, and other clippable items Available at TheOontZ.com: TheOontZ.com/angle3-carry-case...
