- Page 1 Guide version 2.0 Please go to our website TheOontZ.com For getting started videos & tips, FAQs and latest manual updates © copyright SoundWorks Inc.
- Page 2 Table of Contents Thank you very much for selecting the OontZ Angle! We hope that you will love it! The OontZ Angle is designed to play your music wirelessly with high quality, and be simple and fun to use. This guide was written to help you get started quickly.
- Page 3 Smartphones and tablets with Bluetooth*. The rechargeable battery will provide up to 10 hours** of continuous listening. With the built-in microphone you can use your OontZ Angle as a wireless hands free personal speaker phone when connected by Bluetooth* to most iPhones or Smartphones. You can also...
-
Page 4: In The Box
Please go to our website TheOontZ.com For getting started videos & tips, FAQs and latest manual updates © copyright SoundWorks Inc. 1 - OontZ Angle Guide 1 - OontZ Angle 1 - Micro USB Cable (For Charging Only) 1 – 3.5mm Audio (Line-In) Cable... - Page 5 3. The Buttons and connectors 1. “VOL+” Button --Press to increase the volume 2. “Bluetooth symbol and phone icon” Button -- Press and hold for about 5 to 6 seconds to go into Bluetooth pairing mode. For incoming calls on speaker phone: press and release to answer a call;...
- Page 6 8. Microphone icon – This is the microphone for the hands free speaker phone 9. Pairing Indicator light – When the OontZ Angle is powered on the light will be blue; when the OontZ Angle is in pairing mode the light will be blue with flashing red;...
-
Page 7: Charging The Battery
Important Note: It is recommended that you remove the charging cable after the OontZ Angle is fully charged. **The OontZ Angle, when fully charged, has a play time of up to 10 hours, depending on volume.. The play time varies for a number of reasons including the volume (the louder the volume, the shorter the play time), device, connection, and music type. - Page 8 It is quick and easy to pair and wirelessly connect to your Bluetooth device by following these steps: Step 1 – Make sure your OontZ Angle has sufficient charge or connect to a charging “ON/OFF” Switch to the on source. Turn on the OontZ Angle, by sliding the position.
- Page 9 “Bluetooth symbol and phone icon” Button for about 5 to 6 seconds until hold the the Pairing Indicator light on the front of the front of the OontZ Angle is blue with flashing red. The blue light with flashing red indicates the device is disconnected and the OontZ Angle is in pairing mode.
- Page 10 Bluetooth pairing instructions for your laptop or MacBook. You will need to first set up the OontZ Angle as a device on your system, and then select it from the list of set up devices. The OontZ Angle may show up on the list of Bluetooth devices before it is even set up.
- Page 11 Ending a call: To end a call press and hold the Button for about 3 seconds. Note: 1. The incoming call will be heard on the OontZ Angle and your voice will be picked up by the microphone. Please have the microphone faced towards you and keep a close proximity to the microphone to have your voice clear to the listener.
- Page 12 Step 2 – Plug one end of the 3.5mm audio cable into the “AUX IN” Jack (see Section 3: item 6) on the OontZ Angle and plug the other end into the headphone jack on your device or laptop. You can then play your music and audio on the OontZ Angle.
-
Page 13: Troubleshooting
Disconnect the other device from the OontZ Angle. appears on my device, but will Make sure volume is up on your device and the OontZ Angle. not connect Turn the OontZ Angle off then on again. Make sure the OontZ Angle is not currently connected to Paired any other device. - Page 14 Bluetooth. Make sure the 3.5mm audio cable is fully inserted into the No Audio OontZ Angle and Device. Some devices have cases that from AUX prevent a proper fit and need to be removed to connect. source Make sure your device is on and playing and music is not paused.
- Page 15 10. Safety and Precautions Page 14...
- Page 16 10. Safety and Precautions (continued) Page 15...
- Page 17 10. Safety and Precautions (continued) Page 16...
