- Page 1 Quick Start Guide Portable Mini Bluetooth Speaker Designed and Engineered By TheOontZ.com...
- Page 2 In the Package Quick-Start Guide Micro USB Charging Cable Lanyard Note: The cable and lanyard are packed below the cardboard insert in the box. Slide out the insert to locate them.
-
Page 3: Table Of Contents
Table of Contents Pages 1 - 3 Buttons, Lights and Connectors Attaching the Lanyard 5 - 7 Battery Features and Charging the Battery Turning On and Off Pair & Connect with Your Device 9 - 12 To Play with Non-Bluetooth Devices use a 3.5mm Audio Cable IPX5 Water Resistance Wireless Hands Free Personal Speakerphone Reset Function... -
Page 4: Buttons, Lights And Connectors
Buttons Bluetooth Play/Pause (Dual Function) Press and Release to Pause/Play Button Button (Dual Function) (Dual Function) Volume Down Volume Up Press to decrease volume Press to increase volume Track Back Track Forward Power Press and Hold Down to go to the Press and Hold Down beginning of the track to go to the next track... - Page 5 Lights Blue Light lit when speaker is on: - Flashing Blue speaker is in pairing mode - Solid Blue speaker is connected - Blue Light will turn to Solid Green when the 3.5mm audio cable is plugged into the AUX IN Jack Red Light lit when charging: - Slowly flashing Red battery is charging...
- Page 6 Connectors Built-in Mic for AUX IN Jack Micro USB Speakerphone Charging Connector Rubber Flap - covers connectors - pull gently from the top to access connectors, it is a snug fit to provide water resistance Note: The rubber flap needs to be closed to keep the speaker water resistant Page 3...
-
Page 7: Attaching The Lanyard
Attaching the Lanyard Use the lanyard as a wrist strap for carrying your speaker in hand or attaching to other objects - Slide the smaller - Slide the larger lanyard - Pull the larger lanyard lanyard loop through loop through the loop completely one of the lanyard smaller lanyard loop... -
Page 8: Battery Features And Charging The Battery
- When playing from battery power the speaker is ready to play. OontZ Angle Solo will turn off after 30 minutes of not playing audio to - For maximum playtime, fully conserve the battery charge. * charge the battery. - Page 9 Charging the Battery - Insert the small end of the Micro USB Charging Cable into the Micro USB Charging Connector as shown. - Insert the large end of the Micro USB Charging cable into either a USB wall charger for a Smartphone or iPhone, or a USB port on your laptop/computer to charge the battery (see...
- Page 10 Insert the large end of the Micro USB charging cable into either a USB wall charger for a Smartphone or iPhone (a USB wall charger that is 5V 1.0A up to 5V 2.4A maximum) or a USB port on your laptop/computer to charge the OontZ Angle Solo rechargeable battery. Page 7...
-
Page 11: Turning On And Off
The speaker is in pairing mode - Solid Blue Your device has connected with the OontZ Angle Solo and is ready to play Turn OFF Press and Hold Down the Power Button for 2 Seconds Blue Light will turn off... -
Page 12: Pair & Connect With Your Device
- To disconnect the current device, press and hold down the Bluetooth button for 5 seconds. - The Blue Light will begin flashing and the OontZ Angle Solo is ready for the next device to pair and connect. *Exception: certain devices may not automatically reconnect. Amazon Echo devices will not automatically reconnect. - Page 13 -- With Your iPhone, iPad, or iPod - Go to Settings > Bluetooth, check Bluetooth is on - Select 'OontZ Angle Solo xxx' when it appears under DEVICES (xxx: 3 characters which are unique to your speaker) - Your device will connect in a few seconds...
- Page 14 - Select your Amazon Echo device under 'Devices' by pressing it - Press 'Bluetooth' - Select the 'OontZ Angle Solo xxx' (xxx: 3 characters unique to your speaker) when it appears in the list of 'Available Speakers' - Alexa will announce: "Connected to OontZ Angle Solo"...
-
Page 15: Pair & Connect With Your Device
This will use up the battery charge. We recommend to: 1) Keep the OontZ Angle Solo plugged into a USB wall charger and it will remain on and available to play from the Amazon Echo device until you manually turn the speaker power off. -
Page 16: To Play With Non-Bluetooth Devices Use A 3.5Mm Audio Cable
- Make sure both ends of the cable are fully inserted - You are now ready to play. Important: The Bluetooth on the OontZ Angle Solo is disabled when the 3.5mm audio cable is connected to the speaker. You need to remove the 3.5mm audio cable from the speaker in order to connect to a Bluetooth device. -
Page 17: Ipx5 Water Resistance
IPX5 rating - The OontZ Angle Solo can resist water spray & splash but cannot be partially or fully submerged or left in a wet environment for an extended period of time, any of which could cause unrepairable damage to the speaker. -
Page 18: Wireless Hands Free Personal Speakerphone
Wireless Hands Free Personal Speakerphone The Wireless Hands Free Personal Speakerphone feature works over Bluetooth with Smartphones and iPhones only; this feature is not supported when connected to other types of devices. To answer an Incoming Call / To End a Call - Press and Release the Bluetooth Button To Reject an Incoming Call - Press and Hold Down the Bluetooth Button... -
Page 19: Reset Function
Reset Function Step 1: Remove the Micro USB charging cable and 3.5mm Audio cable, if connected. Step 2: Press and hold down the Power button for approximately 15 seconds until the red and green lights come on together and then turn off together, then release the Power button. -
Page 20: Contacting Customer Support
Customer Support If you have a question about your OontZ Angle Solo or experience an issue with the speaker, our Customer Support Team wants to assist you. For online troubleshooting tips please visit: TheOontZ.com/troubleshooting and select the OontZ Angle Solo Contact us at: TheOontZ.com/support... -
Page 21: Safety And Precautions
Safety and Precautions When the OontZ Angle Solo speaker is plugged in to a charging source with the Micro USB charging cable, never use the speaker in the shower, bath, or near water, to prevent risk of electric shock. Read and follow all instructions – All operating and use instructions should be followed. -
Page 22: Safety And Precautions
Safety and Precautions (continued) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
