Summary of Contents for Eyevision EV-H298
- Page 1 Net-link Eyevisi n Eyevisi n Eyevisi n Eyevisi n Eyevisi n Eyevisi n Eyevisi n Eyevisi n Eyevisi n Eyevisi n Eyevisi n Eyevisi n EV-H304-4B EV-H304F-4B EV-H304KP EV-H304FKP EV-H298KP EV-H298 EV-H298FKP Eyevisi n Net Link EV-H7 V2.1 21/08/19...
- Page 2 Jumper settings for Indoor Monitor and Netlink Page 3 Outdoor station Installation Height Power adapter and Power supply limitations Page 4 EV-H298 (non keypad) outdoor station installation and wiring Page 5 EV-H298KP outdoor station installation and wiring Page 6 EV-H304 outdoor station installation and wiring...
-
Page 3: Installation Hints
Precautions Due to our constant developments, your purchased model functions may vary slightly to the instruction manual provided. We always endeavor to try to update our manuals regularly in accordance with the level of new development. Connect this unit ONLY to other compatible units, Do not connect it to any other type of alarm or auxiliary device. Connecting anything else to this unit may damage it or prevent it from operating correctly. - Page 4 EV-H7 Indoor Monitor Front View Rear View J2 Jumper J1 Jumper V(+12V) GND (Negative) CN 1 (1st Outdoor station) CN 2 (2nd Outdoor station) Wiring and Distances for Intercom line - Maximum of FOUR indoor monitors - Maximum of TWO outdoor units Recommended Cable Type: 4 Core Shielded .030mm up to 100m distance.
- Page 5 Outdoor Station installation height Please install the door station at a height no less than 145cm to the center of the door stations camera. Recommended height is between 145cm-160cm. If the door station is mounted to low the camera may fail in seeing the guests face and will also present issues for communication.
- Page 6 H298 Standard Outdoor Station H298 Installation into the rain cover H298 Front & Rear View Rain Cover Plastic wall plug Screws Speaker LED Light Camera Unlock Intercom connection Connection Name Plate Call Button System Microphone Wiring Rain Cover Screws Automatic Gate System Connection Intercom Line 1.
- Page 7 H298 Keypad Outdoor Station H298KP Installation into the rain cover H298KP Front & Rear View Rain Cover Speaker LED Light Plastic wall plug Screws Camera Intercom Name Plate Call Button connection Exit Button Power Supply System Connection Keypad Wiring Unlock Rain Cover Connection Screws...
- Page 8 H304 Keypad Outdoor Station H304KP Installation into the rain cover H304KP Front & Rear View Eyevisi n Eyevisi n Rain Cover Speaker Camera Plastic wall plug Screws Unlock Intercom Connection LED Light connection Call Button Power Supply System Keypad Connection Wiring Rain Cover Screw...
- Page 9 H304-4B Apartment Outdoor Station H304-4B Installation into the rain cover H304-4B Front & Rear View Eyevisi n Eyevisi n Rain Cover Speaker Camera Plastic wall plug Screws Unlock Intercom Connection LED Light connection Exit Button Power Supply Call Buttons System Connection Wiring Rain Cover...
-
Page 10: System Expansion
Apartment System Wiring Wiring Layout One Outdoor Station System Expansion Apartment 1 Apartment 2 Netlink Expansion Each apartment that has its own internet Adapter connection can have its own netlink Netlink installed so that they can receive calls on CN 1 CN 1 for apartment 2 iOS and Android devices. - Page 11 Home System Wiring Wiring Layout One Outdoor Station and One Monitor (With Netlink) Door Striker or Auto Gate CN 1 Keypad Door Adapter Stations Only Adapter Wiring Layout One Outdoor Station and One Monitor (Without Netlink) CN 1 Door Striker or Auto Gate Keypad Door Adapter...
- Page 12 Home System Wiring continued Wiring Layout Two Outdoor Station and Two Monitors (With Netlink) 2C 2C 2C 2C CN 1 CN 1 CN 2 CN 2 CN 1 CN 1 CN 2 CN 2 CN 1 CN 1 Adapter Adapter Adapter Adapter Netlink...
- Page 13 Home System Wiring continued Wiring Layout Two Outdoor Station and Four Monitors (With Netlink) CN 1 CN 2 CN 2 CN 1 CN 2 CN 1 CN 2 CN 1 Adapter Adapter Adapter Adapter Netlink Adapter CN 3 CN 2 CN 1 Door Striker Door Striker...
- Page 14 Answering Visitor Calls Monitoring Transferring the Call Page 12...
- Page 15 Keypad Setup Guide 1. Information *The factory default programming password is *1234, this is NOT the PIN number. *In the programming mode you can set up to 40 groups of 4-digit PIN numbers to unlock. * 30 Groups have adjustable unlock time and 10 are fixed on a momentary pulse. 2.
- Page 16 Setting the unlock time for H298 (Non Keypad) and H304 Apartment outdoor station This procedure is performed from the standby state and will need to be set on all monitors in the installation. The default setting is one second (pulse). 1.
-
Page 17: Important Notes
Net Link Setup Guide Android users can download ControlCam 2 App from Google Play while iOS users can download it from iOS App Store. Complete the installation on your smart phone(or tablet) before proceeding. Setup and Log in with a New User Account 1. - Page 18 GOTO the WiFi settings on your phone/tablet and connect to the network named LIDAWxxxxx “LIDAW..” ,you will be prompted there is no internet connection available on eyevision this network which is correct. 2. Enter the ControlCam2 APP 3. Press the “+” button to add a device 5.
- Page 19 4. Choose the Doorbell 1/Type 1 option. On the following screen press Next eyevision 6. Then the name of your local Wi-Fi network should then appear as shown. Do not enter the password yet. 7. Minimize the controlcam2 APP and GOTO the WiFi settings on your eyevision phone/tablet and connect to the network named“LIDAW..”...
- Page 20 Configuring the Netlink via Controlcam 2 1. Change Device and Unlock Password The default password for the outdoor station is 1234 so you should change the default password as soon as possible (after adding the outdoor station to your app). 1.
-
Page 21: Troubleshooting
Setup via Hard-Wired Ethernet Connection Adding an Existing Device to a new phone or tablet There are 3 methods for adding an outdoor station which has been hard-wired to the Local Area Network - or one which has previously been added and configure via WiFi (for example, from another smart device) This process applies to both the iOS and Android apps.
