- Page 1 Eyevisi n WI-FI Intercom System Eyevisi n Eyevisi n Eyevisi n Eyevisi n Eyevisi n Eyevisi n Eyevisi n WF-D01FKP WF-D01FKP WF-D02S WF-D01TKP WF-D01TFKP WF-D01KP 21/02/19...
-
Page 2: Table Of Contents
Table of Contents Page 1 Installation Hints Precautions Hardwired connection using ethernet cable Power adapter and Power supply limitations Page 2 Outdoor station Installation Height Outdoor Station Overview Page 3 Outdoor station installation and wiring WiFi antenna connection Rj45 Jack connection Page 4 Keypad Programming including unlock time setting Page 5... -
Page 3: Installation Hints
Precautions Due to our constant developments, your purchased model functions may vary slightly to the instruction manual provided. We always endeavor to try to update our manuals regularly in accordance with the level of new development. Connecting anything else to this unit may damage it or prevent it from operating correctly. Do not place the power cords from the AC/DC adapters, camera or monitor where they can be pinched or cut. - Page 4 2. Exit Button (Second Wire- COM) 3. Relay N/O Camera 4. Relay Common Name Plate Call Button Microphone 5. Relay N/C WF-D02S Installation into the rain cover WF-D01KP Installation into the rain cover Rain Cover Rain Cover Plastic wall plug Plastic wall plug Screws Screws...
-
Page 5: Wifi Antenna Connection
RJ 45 Cat 5 Connector WIFI Antenna Connection To 5 PIN Adapter RJ 45 Connection WIFI Antenna Port 1. Align the antenna connector to the WIFI port. 2. Press in FIRMLY to ensure that the connector is locked into the port. Automatic Gate System Connection CN 3 CN 2... - Page 6 WF-D01KP/D01TKP and D01FKP Setup Guide 1. Information *The factory default programming password is *1234, this is NOT the PIN number. *In the programming mode you can set up to 40 groups of 4-digit PIN numbers to unlock. * 30 Groups have adjustable unlock time and 10 are fixed on a momentary pulse. TWO OPTIONS: 2.
- Page 7 WF Series Setup Guide Android users can download ControlCam 2 App from Google Play while iOS users can download it from iOS App Store. Complete the installation on your smart phone(or tablet) before proceeding. Setup and Log in with a New User Account 1.
- Page 8 GOTO the WiFi settings on your phone/tablet and connect to the network named LIDAWxxxxx “LIDAW..” ,you will be prompted there is no internet connection available on eyevision this network which is correct. 2. Enter the ControlCam2 APP 3. Press the “+” button to add a device 5.
- Page 9 4. Choose the Doorbell 2/Type 2 option. On the following screen press Next eyevision 6. Then the name of your local Wi-Fi network should then appear as shown. Do not enter the password yet. 7. Minimize the controlcam2 APP and GOTO the WiFi settings on your eyevision phone/tablet and connect to the network named“LIDAW..”...
- Page 10 Configuring the WiFi Intercom via Controlcam 2 1. Change Device Password The default password for the outdoor station is 1234 so you should change the default password as soon as possible (after adding the outdoor station to your app). 1. From the home screen within the APP press the icon.
-
Page 11: Setting The Date And Time
6. Setting the Date and Time 1. From the home screen within the APP press the icon. 2. Press Advanced Settings 3. Select Set Time 4. You will be prompted “Sync camera time with your device?” Press OK 7. Delete the Outdoor Station 1. -
Page 12: Troubleshooting
Troubleshooting Problems requiring Preliminary setup or as a result of a incorrect preliminary setup (page 6/7) - I can view the outdoor station on WiFi at home but not on 3G/4G - I can receive calls from the outdoor station on WiFi at home but not on 3G/4G I used to receive notifications on my phone but not anymore - Ensure your controlcam 2 user account is not in use on another device, each device needs its own account.
