- Page 1 Leica FL400 for M530 User Manual 10 744 764 - version 02...
- Page 2 The information provided by this manual is directly related to the operation of the equipment. Medical decision remains the responsibility of the clinician. leica Microsystems has made every effort to provide a complete and clear user manual highlighting the key areas of product use. should additional information regarding the use of the product be required, please contact your local leica representative.
-
Page 3: Table Of Contents
Fl400 functions Care and maintenance What to do, if… General leica Fl400 for M530 Technical data Technical data leica Fl400 for M530 compatibility ambient conditions Manufacturer's declaration of electromagnetic compatibility (EMC) leica Fl400 for M530 / Ref. 10 744 764 / version 02... -
Page 4: Introduction
The leica Fl400 for M530 is an accessory for leica surgical representative for availability. microscope systems. in this user manual the functions of the leica Fl400 for M530 are described. For information and description of the leica surgical Product identification microscope, please refer to the user manual of the particular surgical microscope. -
Page 5: Safety Notes
Safety notes Signs and labels Type label a leica surgical microscope with leica Fl400 for M530 is state-of- The type label is located on the side of the leica Fl400 for M530 the-art technology. nevertheless, hazards can arise during filter module. operation. -
Page 6: Description
Leica OHX • interface for assistants, either to the left and right side or to the back on the swing arm the following leds are significant for the Fl400 • Main surgeon and back assistant interface, 360° rotatable both application: •... - Page 7 Working Magni- fication distance fication FL400 mode X– on/o FL400 mode on/off Selected brakes function no function Y– Magni- Working Magni- fication distance fication FL400 mode on/off Selected brakes leica Fl400 for M530 / Ref. 10 744 764 / version 02...
-
Page 8: Preparation Before Surgery
The selected user preset is displayed in the top line. The Fl400 user presets are only available if the Fl400 either "White light" or "Fl400 Blue light" is displayed on the accessories are enabled in the accessory list in the service right side. - Page 9 "show settings" button. select the "Handle left" or "Handle Right" tab. select "new User". open the "Handle left" or "Handle Right" tab to assign Fl400 functions to the handle. You see an overview with which buttons of the selected handle the Fl400 functions can be operated.
- Page 10 "save" button to save your settings under the user name entered at the desired location. Brightness open the "Fl" tab to set the brightness in Fl400 mode to an adequate level. decide if the working distance limitation in White light mode should be switched on (default) or off.
- Page 11 The selected user preset is displayed in the top line. Using the "Fluorescence Oncology FL400" user preset either "White light" or "Fl400 Blue light" is displayed on the right side. The Fl400 user presets are only available if the Fl400 accessories are enabled in the accessory list in the service menu of your leica M530 oHX.
- Page 12 "Handle left" or "Handle Right" tab. "User settings". select "new User". open the "Handle left" or "Handle Right" tab to assign Fl400 functions to the handle. You see an overview with which buttons of the selected handle the Fl400 functions can be operated.
-
Page 13: Pre-Operation Checklist
Operational check switch on the microscope. Brightness switch on the illumination. open the "Fl" tab to set the brightness in Fl400 mode to an select an Fl400 user. adequate level. check visually whether the microscope illumination has switched from white to blue light. -
Page 14: Operation
Fl400 user. The status led on the swing arm of the particular surgical microscope is illuminated in blue if the Fl400 mode is active, and white if switched back to white-light mode. if the illumination fails in the white-light or Fl400 mode, change to the second illumination source of the illumination unit. -
Page 15: What To Do, If
Fl400 mode not active the control unit display the Fl400 mode. check whether the Fl400 on/oFF function is assigned to a button of the handle. leica Fl400 for M530 / Ref. 10 744 764 / version 02... -
Page 16: Technical Data
Transport –30 °c to +70 °c particular surgical microscope system. –86 °F to +158 °F 10 % to 100 % rel. humidity 500 mbar to 1060 mbar atmospheric pressure leica Fl400 for M530 / Ref. 10 744 764 / version 02... -
Page 17: Manufacturer's Declaration Of Electromagnetic Compatibility (Emc)
10 Manufacturer's declaration of electromagnetic compatibility (EMC) For the eMc declaration of the leica Fl400 for M530, please refer to the user manual of the particular leica surgical microscope system. leica Fl400 for M530 / Ref. 10 744 764 / version 02... - Page 18 M530 / Ref. 10 744 764 / version 02...
- Page 19 M530 / Ref. 10 744 764 / version 02...
- Page 20 10 744 764en/02 • Copyright © by Leica Microsystems (Schweiz) AG, Medical Division, CH-9435 Heerbrugg, 2014 • Printed – X.2014 – Editing for printout by galledia • Subject to modifications. • LEICA and the Leica Logo are registered trademarks of Leica Microsystems IR GmbH.
