Home Styles 88 5522 9413 Quick Start Manual

88 5522 9413
Kitchen Island
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.

Part List

D.
Middle Panel
1 pc.
I.
Base
1 pc.

Hardware List

Cam Lock
18 pcs.(+4 extra)
Cam Lock Screw
18 pcs.(+2 extra)
Also need the part(s) from carton 88 5522 9412, 88 5522 9411 or 88 5522 9421
Tools required for assembly : Phillips screwdriver
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
E.
Back Stretcher
1 pc.
H.
Front Rail
1 pc.
L.
Shelf
3 pcs.
M3x15
Wood Screw
for Magnet Magnet
2 pcs.(+1 extra) 1 pc.
M3x25
Wood Screw (long)
for Drawer Side Part Adjustable Pin
8 pcs. (+1 extra) 12 pcs. (+1 extra)
M.
Door
(Please refer to the last page(s) of
1 pc.
instructions for steps to complete drawer assembly)
M3x15
Wood Screw (short)
for Drawer Base Part
and Back Panel
18 pcs. (+1 extra)
M3x19
Flat Head Screw Pull Handle
9 pcs. (+1 extra) 1 pc.
Tools recommended for assembly :Level
PATENE 8,584,600 B2
F. G.
Upright
Back Panel
1 pc.
2 pcs.
N.
Drawer
1 pc.
M4x22
Machine Screw
3 pcs.
Pull Handle
1 pc.
