88 5522 16
Student Desk
Important NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
PART LIST
A.
Top Section
1 pc.
E.
Drawer Front
1 pc.
HARDWARE LIST
Key Wrench
1 pc.
M8x45
Bolt
8 pcs. (+1 extra )
Tools Required For Assembly : Phillips screwdriver
Spring Washer
8 pcs. (+1 extra )
Flat Washer
8 pcs. (+1 extra )
B.
C.
Leg
Leg
1 pc.
1 pc.
M4x32
Machine Screw
4 pcs. (+1 extra )
M3x10
Wood Screw
Pull Handle
2 pcs.
9 pcs. (+1 extra )
D.
Leg
2 pcs.
