- Page 1 NEOLINE SERIES 1000 – 2000 – 3000 1000XL – 2000XL – 3000XL 1 Phase In - 1 Phase Out USER MANUAL...
- Page 3 Thank you for purchasing product. Observe the warnings on the machine and manual strictly and properly keep the manual. Do not operate the UPS before read safety notes and operation instructions.
-
Page 4: Table Of Contents
TABLE CONTENT 1. Introduction ............................. 2 1.1 Description of Commonly Used Symbols ..................2 1.2 Safety Instructions ......................... 2 Product Description ..........................4 2.1 System Type and Configuration ....................4 2.2 The Appearance of the UPS ......................5 2.3 Operating Principle ........................6 Installation .............................. -
Page 6: Introduction
1. Introduction 1.1. Description of Commonly Used Symbols Some or all of the following symbols may be used in this manual and may appear in your application process. Therefore, all users should read the form carefully and thoroughly. 1.2. Safety Instructions 1. - Page 7 6. Do not open or mutilate the battery or batteries, released electrolyte is highly poisonous and harmful to the skin and eyes. 7. Do not short the positive and negative of battery electrode. Otherwise, it may cause electric shock or fire. 8.
-
Page 8: Product Description
1kVA, 2kVA and 3kVA UPS. Table 2-1 UPS types and configurations Type Model Remark 1kVA UPS NEOLINE 1000 With a 1A internal charger and 3 batteries Standard 2kVA UPS NEOLINE 2000 With a 1A internal charger and 6 batteries... -
Page 9: The Appearance Of The Ups
2.2 The Appearance of the UPS Computer Interface (RS232) Intelligent Slot Surge Protection Output Breake Input External battery connector Figure 2-1 The Appearance of NEOLINE 1000XL UPS Intelligent Slot Computer Surge Interface Protection (RS232) Output External battery Breaker connector Input Figure 2-2 The Appearance of NEOLINE 2000XL UPS... -
Page 10: Operating Principle
Computer Intelligent Slot Interface Surge (RS232) Protection Output Terminal Block Cover External Terminal battery Block Breaker connector Input Figure 2-3 The Appearance of NEOLINE 3000XL UPS 2.3. Operating Principle Figure 2-4 The UPS operating principle... - Page 11 1. Input filter: Perform a filter for input .It provides clean AC power to the UPS. 2. AC/DC Boost：In Normal mode, it converts the AC input power to regulated DC power. 3. DC/DC converter: Raises the DC Voltage from the battery system to the optimum operating voltage for the inverter when the UPS operates in Battery mode.
-
Page 12: Installation
3. Installation 3.1 Unpacking Inspection 1. Open the packing box of UPS and take them out, visually examine the units for transit damage. 2. Check against the accessory lists that the accessories of the UPS are present. (Refer to Table 3-1) 3. -
Page 13: Cable Connection
If the UPS is connected via the power cable, please use a proper socket with protection against electric current, and pay attention to the capacity of the socket: over 10A for NEOLINE 1000(XL) and NEOLINE 2000(XL),over 16A for NEOLINE 3000(XL). The wiring configuration is shown in the following diagram. - Page 14 Figure 3-2 Connection method of output for NEOLINE 1000(XL)～NEOLINE 3000(XL) Apart from using the socket for output, NEOLINE 3000(XL) has the terminal block available for output as well. The wring configuration is shown in the following diagram. Remove the small cover of the terminal block;...
-
Page 15: Operation Procedure Of External Battery For Long Backup Time Ups
Figure 3-3 Connection method of terminal block for NEOLINE 3000(XL) Caution: Do not connect the loads with terminal block by the personal without qualified training. 3.3.2 Operation Procedure of External Battery for Long Backup Time UPS The battery connection procedure is very important. Any incompliance may result in the risk of electric shock. -
Page 16: Connecting Communication Interface
4. Connect the plug of the external battery cable to the external battery socket on the rear panel of the UPS to complete the connection procedure and the UPS starts to charge the battery pack. Figure 3-4 Battery connection diagram for Long Backup time models ：... - Page 17 1. Computer interface Computer interface: The type of signals, serial command (RS232), is provided by the UPS to communicate with a host computer. User can use WinPower software to monitor the UPS through the RS232 communication port.
-
Page 18: Operation
2. Alternative connection of communication Intelligent Slot－ The intelligent slot is designed for installing the AS400 card，SNMP card and CMS card. You can choose for one of them to install. a－AS400: You can utilize AS400’s monitor function to manage the power supply directly. b－SNMP: It enables you monitor the UPS remotely through Internet c－CMS:Central monitor card ：... - Page 19 Display Function Display Panel The following table describes the function of the button switches of the front panel. Button Function This button has two functions: -Turning on the UPS system: By pressing this button the UPS system turns on. -Shut off the UPS system: ON/OFF-Button When mains power is normal, the UPS System switches to Bypass mode by pressing OFF button...
- Page 20 FAULT lighting indicates mode code, fault code and warning code, which could be displayed from 0 to99 ,SET lighting indicates the set code, type V (set voltage), F (set frequency) BATTERY lighting indicates the battery voltage value, which could be displayed from 0 to 999Vdc; TEMP lighting indicates the ups inside temperature, which could be displayed from 0 to 999℃(The...
-
Page 21: Operation Mode
LCD display 4.2 Operation Mode 4.2.1 Line mode The LCD display in line mode is shown in the following diagram. The information about the utility power, the battery, the temperature and load could be displayed, The operating mode code of the UPS is "03"... -
Page 22: Bypass Mode
Line mode 4.2.2 Bypass mode The LCD display in bypass mode is shown in the following diagram.The information about the utility power,the battery, the UPS temperature and could be displayed.The operating mode code of the UPS is"02".The UPS will beep once every 2 minutes in bypass mode. Bypass mode 4.2.3 Battery mode... -
Page 23: Battery Mode
The LCD display in battery mode is shown in the following diagram. The information about the tility power, the battery, the temperature and load could be displayed. The operating mode code of the UPS is "04". When the UPS is running in battery mode, the buzzer beeps once every 4 seconds. Battery mode 4.3. -
Page 24: Conducting Battery Self-Diagnosis
Connect the mains input to the UPS, press and hold the ON/OFF button for 1 second until the buzzer beeps. At this point, the UPS begins to conduct self-diagnosis, with the load/battery capacity indicators on the front panel turned on and then off one after another. Seconds later, the UPS will begin to operate in Normal mode;... -
Page 25: Maintenance
5. Maintenance 5.1 Battery Maintenance... -
Page 26: Checking Ups Function
The battery is key component of the UPS. The battery life depends on the ambient temperature, charge and discharge times. High ambient temperature and deep discharge will shorten the battery life. 1. Sealed maintenance-free lead –acid battery be used in the standard. When being connected to the utility whether the UPS has been turned on or not, the UPS keeps charging the battery and also offers the protective function of charging and discharging. -
Page 27: Troubleshooting
If the main voltage is within the specifications, the UPS should operate in normal mode; if the main voltage is abnormal, the UPS should operate in battery mode. In both cases, there should be no fault indication. 2. Check the transfer between the UPS operation modes Disconnect the main input to simulate a mains failure, the UPS should transfer to battery mode and operate normally;... -
Page 28: Specifications
Problem Possible cause solution Ensure that the UPS is not overloaded and the ventilation opening is not blocked and Display Fault 4 ambient temperature is not too high. Wait for Internal overheat Buzzer long 10 minutes for the UPS to cool down before turning it again. -
Page 29: Mechanical
Charger to 90% battery capacity in 5 hours（Standard） Battery charge time Dependent on the capacity of external batteries（Long backup time） 7.2 Mechanical Model W*H*D(mm) Weight(kg) NEOLINE 1000 145×220×355 12 kg NEOLINE 1000XL 145×220×355 6.5 kg NEOLINE 2000 190×318×383 23 kg... -
Page 30: Environmental
NEOLINE 2000XL 190×318×383 10.5 kg NEOLINE 3000 190×318×433 28 kg NEOLINE 3000XL 190×318×433 11.5 kg 7.3 Environmental Item Normal range Ambient temperature 0℃～40℃ Environment humidity <95% Altitude Lower than 1000m Storage temperature -15℃～45 ℃ 7.4 EMC Item Standard Level IEC61000-4-2 LEVEL4 LEVEL4 IEC61000-4-3 LEVEL3 LEVEL3... - Page 31 This limited warranty does not apply to conditions as follows: Man-made fault; Out of warranty; The finished product of which the serial number is changed or lost; Damage or loss resulted from force majeure or external causes; Disassembly or modifications to the unit with no authorization; Disobeying provisions of operating/using the unit;...
- Page 32 AGKK10440 12/2012...
