- Page 1 NEOLINE 6-20KVA UPS High Frequency Online UPS Uninterruptible Power System USER MANUAL...
- Page 2 Please comply with all warnings and operating instructions in this manual and on the unit strictly. Save this manual properly. Do not operate this unit before reading through all safety information and operating instructions carefully.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY AND EMC INSTUTIONS ................... 1 1.1 Installation ......................... 1 1.2 Operation .......................... 1 1.3 Maintenance servicing and faults ..................1 1.4 Transport .......................... 2 1.5 Storage ..........................2 1.6 Standards ......................... 3 DESCRIPTION OF COMMONLY USED SYSMBOLS ............4 III. -
Page 5: Safety And Emc Instutions
1. IMPORTANT SAFETY INSTRUCTION 1.Safety and EMC instructions Please read carefully the following user manual and the safety instructions before installing the unit or using the unit! 1.1 Installation ■ Condensation may occur if the UPS is moved directly from a cold to a warm environment. The UPS must be absolutely dry before being installed. -
Page 6: Maintenance Servicing And Faults
1.3 Maintenance, servicing and faults ■ The UPS operates with hazardous voltages. Repairs may be carried out only by qualified maintenance personnel. ■ Caution - risk of electric shock. Even after the unit is disconnected from the mains power supply (building wiring terminal), components inside the UPS are still connected to the battery which are potentially dangerous. -
Page 7: Standards
1.6 Standards * Safety IEC/EN 62040-1-1 * EMI Conducted Emission IEC/EN 62040-2 Category C3 Radiated Emission IEC/EN 62040-2 Category C3 *EMS IEC/EN 61000-4-2 Level 4 IEC/EN 61000-4-3 Level 3 IEC/EN 61000-4-4 Level 4 SURGE IEC/EN 61000-4- Level 4 Low Frequency Signals IEC/EN 61000-2-2 Warning: This is a product for commercial and industrial application in the second environment-installation restrictions or... -
Page 8: Description Of Commonly Used Sysmbols
2. Description of commonly used symbols Some or all of the following symbols may be used in this manual. It is advisable to familiarize yourself with them and understand their meaning:... -
Page 9: Introduction
3. Introduction 3.1 System and model description The On-Line-Series is an uninterruptible power supply incorporating double-converter technology. It provides perfect protection specifically for strict load. The double-converter principle eliminates all mains power disturbances. A rectifier converts the alternating current from the socket outlet to direct current. This direct current charges the batteries and powers the inverter. -
Page 10: Electrical Performance
2)Electrical performance INPUT Power Factor Model Voltage Frequency 50/60Hz±5% Single-phase NEOLINE106XL / 110XL >0.99(Full load) （adjustable） 220VAC - 230VAC NEOLINE 210XL Three-phase 50/60Hz±5% NEOLINE 215XL 380VAC/220 VAC >0.95(Full load) （adjustable） NEOLINE 220XL 380VAC/230 VAC OUTPUT Voltage Power Current Frequency tolerance Distortion Overload capacity regulation... -
Page 11: Dsplay Panel
4. Display Panel LCD Screen On/Off Button Select-Button Enter-Button he following table describes the function of the button switches of the front panel. Button Function This button has two functions: - Turning on the UPS system: By pressing this button the UPS system turns on. ON/OFF Button - Shut off the UPS system: When mains power is normal, the UPS System switches to Bypass mode by pressing OFF button , and the inverter is off . -
Page 12: Installation
Display Function FAULT lighting indicates mode code, fault code and warning code, which could be displayed from 0 to99 ,SET lighting indicates the set code, type V (set voltage), F (set frequency) BATTERY lighting indicates the battery voltage value, which could be displayed from 0 to 999Vdc;... -
Page 13: Installation
5.1 Unpacking and Inspection 1) Unpack the packaging and check the package contents. The shipping package contains: ● A UPS ● A user manual ● A communication cable ● A battery cable (for NEOLINE 106XL/110XL/210XL only 2) Inspect the appearance of the UPS to see if there is any damage during transportation. Do not turn on the unit and notify the carrier and dealer immediately if there is any damage or lacking of some parts. - Page 14 Note: you must make sure that the input and output wires and the input and output terminals are connected tightly. 6) The protective earth ground wire refers to the wire connection between the equipment which consumes electric equipment and the ground wire. The wire diameter of protective earth ground wire should be at least as above mentioned for each model and green wire or green wire with yellow ribbon wire is used.
-
Page 15: Ups With The External Bttery
Input and Output Terminal Block wiring diagram of NEOLINE 210XL/215XL/220XL 5.3 Operating procedure for connecting the long backup time model UPS with the external battery 1. The nominal DC voltage of external battery pack is 192VDC. Each battery pack consists of 16 pieces of 12V maintenance free batteries in series. -
Page 16: Parallel Operation
5.4 Parallel operation 1. Brief introduction of the redundancy N+X is currently the most reliable power supply structure. N represents the minimum UPS number that the total load needs; X represents the redundant UPS number, i.e. the fault UPS number that the system can handle simultaneously. - Page 17 Parallel Installation Diagram 4) To perform the maintenance, follow the stand-alone requirement...
-
Page 20: Operation Mode
6. Operation 6.1 Operation Mode 1. Turn on the UPS with utility power supplied (in Line mode) 1) After you make sure that the power supply connection is correct, and then set the breaker of the battery pack in the “ON” position (this step only for long backup time model), after that set the input breaker in the “ON” position. -
Page 21: Notes For Battery Disposal And Battery Replacement
● The UPS should be charged once every 4 to 6 months if it has not been used for a long time. ● In the regions of hot climates, the battery should be charged and discharged every 2 months. The standard charging time should be at least 12 hours. -
Page 22: Operating Mode Or All Models
Solution Problem Possible cause Make sure the UPS is not overloaded; the The Fault code is air vents are not blocked and the ambient “08”, and the The UPS transfers to fault temperature is not too high.Wait for buzzer beeps mode due to internal overheat. - Page 23 10.1 Bypass mode The LCD display in Bypass mode is shown in the following diagram. The information about the utility power, the battery, the UPS temperature and load could be displayed. The operating mode code of the UPS is “01”. The UPS will beep once every 2 minutes in Bypass mode.
- Page 24 10.3 Battery mode The LCD display in Battery mode is shown in the following diagram. The information about the utility power, the battery, the temperature and load could be displayed. The operating mode code of the UPS is “03”. 1) When the UPS is running in Battery mode, the buzzer beeps once every 4 seconds. If the ENTER button on the front panel is pressed for more than 1 second again, the buzzer will stop beeping (in silence mode).
- Page 25 10.5 Parallel mode The LCD display in parallel mode is shown in the following diagram. When the UPS operating in parallel mode, the operating mode code of the UPS is “P2”. Parallel mode 10.6 Warning mode The LCD display in warning mode is shown in the following diagram. the symbol “WARNING” is shown instead in code display.
- Page 26 10.7 Fault mode The LCD display in fault is shown in the following diagram. The symbol “MODE” not be shown and the symbol “FAULT” is shown instead in code display. Fault mode (Bus Fault) 10.8 Set Mode The LCD display in voltage set is shown in the following diagram. Set Voltage...
- Page 27 The LCD display in Frequency set is shown in the following diagram. 10.9 Battery Low voltage warning The LCD display in Battery Low voltage warning is shown in the following diagram. Notice：When Battery low voltage or short back-up time, both low-voltage marker and clock marker would bright synchronously...
- Page 28 10.10 Battery Low voltage warning The LCD display in Battery Low voltage warning is shown in the following diagram. Note: The above all diagrams: temperature, battery voltage, Input voltage, input frequency, output voltage, output frequency would alternately displayed in each mode (once every three seconds) 11.
- Page 29 11.1 RS232 Interface The following is the pin assignment and description of DB-9 connector. Pin # Description Output Input Input 11.2 Intelligent slot This series is equipped with an intelligent slot for Webpower (optional accessory) or other optional card to achieve remote management of the UPS through internet / intranet.
- Page 30 12. Software for all models Free Software Download – WinPower WinPower is a brand new UPS monitoring software, which provides userfriendly interface to monitor and control your UPS. This unique software provides safely auto shutdown for multi-computer systems while power failure.With this software, users can monitor and control any UPS on the same LAN no matter how far from the UPSs.
- Page 31 Appendix1:Rear Panel BACK VIEW of NEOLINE 106 & NEOLINE 110...
- Page 32 BACK VIEW of NEOLINE 210XL & NEOLINE 215XL & NEOLINE 220XL (1) RS232 (2) Inteligent Solt (3) Fan (4) Parallel Port (5) Input Breaker (6) Maintain Switch (7) Terminal Block Cover (8) Cable Rack (9) EPO(Option) BACK VIEW of NEOLINE 210...
- Page 33 192321142002001...
- Page 34 AGKK10360 10/2019...
