During work on and with the device, the required personal protective equipment must always be worn. Appropriate use VEGATOR 121 is a universal controller for connection of level switches. You can find detailed information about the area of application in chapter " Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions.
Canadian Electrical Code. Safety instructions for Ex areas For applications in explosion-proof areas (Ex), only devices with cor- responding Ex approval may be used. Observe the Ex-specific safety instructions. These are an integral part of the operating instructions and are enclosed with every device with Ex approval. VEGATOR 121 •...
Principle of operation Application area The VEGATOR 121 is a single channel controller for level detection of limit switches with 8/16 mA interface. Via the integrated relay simple control tasks can be solved. Typical applications are monitoring func- tions such as overfill or dry run protection, Optionally an additional second relay can be ordered.
• Protected against solar radiation • Avoiding mechanical shock and vibration • Storage and transport Storage and transport temperature see chapter " Supplement - temperature Technical data - Ambient conditions" • Relative humidity 20 … 85 % VEGATOR 121 •...
Mounting General instructions Mounting options VEGATOR 121 is designed for carrier rail mounting (top hat rail 35 x 7.5 according to DIN EN 50022/60715). Due to its protection rating of IP20, the instrument is suitable for mounting in switching cabinets. It can be mounted horizontally and vertically.
Voltage supply The data for power supply are specified in chapter " Technical data". Connection cable The voltage supply of VEGATOR 121 is connected with standard cable according to the national installation standards. The sensors are connected with standard two-wire cable without shielding. If electromagnetic interference is expected which is above the test values of EN 61326 for industrial areas, shielded cable should be used.
5. Option with fail safe relay: Connect relay to terminal 13/14/15 The electrical connection is finished. Wiring plan OPEN 10 11 12 13 14 15 16 17 Sensor circuit (8/16 mA) Relay output Fail safe relay/second relay output (optional) Voltage supply VEGATOR 121 •...
Page 12
5 Connecting to power supply Information: The connection terminals can be detached towards the front, if neces- sary. This can be useful when working in tight spaces or for exchange of an instrument. VEGATOR 121 •...
– Operating control lamp – Mains voltage on, instrument is operating • – Fault indicator – Fault on the sensor circuit due to sensor failure or line break – The relay deenergises in case of failure • Yellow VEGATOR 121 •...
Page 14
While switching on, the sensors VEGASWING, VEGAVIB, VEGA- WAVE deliver a defined switching sequence in which the switching conditions empty/full/failure are run through. This switching sequence is checked and evaluated when switch-on pulse monitoring is acti- vated. If this does not correspond to the definition or is completey missing, the VEGATOR 121 displays a fault. A function test is only VEGATOR 121 •...
Keep in mind that the switching delay of the sensor and controller accumulate. Function relay 2 (op- A second relay can be ordered as an option for VEGATOR 121. The tional) function of the second relay is determined via this DIL switch. It can be configured as fail safe relay or as second level relay. When config-...
Page 16
1 s. The switching-on impulse delivered by the sensor is controlled by VEGATOR 121. After a time of 6 s after switch- ing on the sensor again, the result of the test will be available on the fail safe output and can be further processed by the PLC.
Interruption of the sensor current for at least 1 s Time until event is available (at least 6 s) Function table "Point level" The following table provides an overview of the switching conditions depending on the set mode and the level. VEGATOR 121 •...
Page 18
> 21 mA Dry run protection, point level Sensor Controller Level Sensor LED yel- LED red Relay Fail safe current (fault) relay (op- (output) tional) approx. 16 mA approx. 8 mA < 3.6 mA > 21 mA VEGATOR 121 •...
Should these measures not be successful, please call in urgent cases 24 hour service hotline the VEGA service hotline under the phone no. +49 1805 858550. The hotline is also available outside normal working hours, seven days a week around the clock.
By doing this you help us carry out the repair quickly and without having to call back for needed information. In case of repair, proceed as follows: VEGATOR 121 •...
Page 21
Clean the instrument and pack it damage-proof • Attach the completed form and, if need be, also a safety data sheet outside on the packaging • Ask the agency serving you to get the address for the return ship- ment. You can find the agency on our homepage. VEGATOR 121 •...
Disposal The device is made of recyclable materials. For this reason, it should be disposed of by a specialist recycling company. Observe the ap- plicable national regulations. VEGATOR 121 •...
That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observ- ing the environmental instructions in chapters " Packaging, transport and storage", " Disposal" of these operating instructions. VEGATOR 121 •...
24 … 65 V (-15 %, +10 %) Max. power consumption 3 W (8 VA) Sensor input Quantity 1 x analogue Input type Active (sensor power supply by VEGATOR 121) Measured value transmission Analogue 8/16 mA Switching threshold Ʋ On 12.1 mA Ʋ Off 11.9 mA...
Page 25
Ʋ Reference voltage 253 V If inductive loads or stronger currents are switched through, the gold plating on the relay contact surface will be permanently damaged. The contact is then no longer suitable for switching low-level signal circuits. VEGATOR 121 •...
For that reason the associated approval documents of these instruments have to be carefully noted. They are part of the delivery or can be downloaded by entering the serial number of your instrument into the search field under www.vega.com as well as in the general download area. 10.2 Dimensions...
