User Guide
EM-PME375
Product overview
Rating plate
©
Danfoss | July 2021
Connections and interfaces
1 Power connections
2 N-end flange mounting
3 Low voltage connector (measurement connector), including low voltage grounding connector
4 Lifting points
5 Cooling system connections (bores)
6 D-end flange mounting
7 Air ventilation plug
Each electric machine has a rating plate which can be found on the machine frame. The rating plate
contains machine rating and identification. The rating values in the Figure below are not correct for this
machine. See the rating plate on the machine and data sheets for the correct values.
BC265857345808en-000201 | 15
