Appendix A: Internal Registers
A Internal Registers
Register
1
2
3
4
Serial status (Modbus TCP)
5
6
7
8
9
10
Serial status (buffered messages)
11
12
13
14
15
16
Serial status (internal requests and web pages)
17
18
19
20
21
22
Configuration registers
23
24
25
26
27
28
29
30
Anybus ® Modbus-TCP/RTU Gateway User Manual
Name
Digital input 1 status
Digital input 2 status
Active MBTCP connections
Active internal connections
Valid responses
Serial time outs
CRC errors
Input buffer overruns
Frame errors
Exceptions responses
Valid responses
Serial time outs
CRC errors
Input Buffer overruns
Frame errors
Exceptions responses
Valid responses
Serial time outs
CRC errors
Input Buffer overruns
Frame errors
Exceptions responses
Modbus TCP Port
Gateway Modbus address
Modbus TCP idle time out
Baud rate
Parity
Number of stop bits
Slave time out time
Physical interface
Values Options
0 or 1
0 or 1
0 - 10
0 - 10
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
0 - 65535
1 - 65535
-1 to 255
-1 Disabled
0 - 255 Enabled
0 - 65535
0 Disabled
1 - 65535 Enabled
2400 2400 bps
4800 4800 bps
9600 9600 bps
19200 19200 bps
38400 38400 bps
57600 57600 bps
115200 115200 bps
0 - 2
0 No parity
1 Even parity
2 Odd parity
1 - 2
25 - 65535
0 - 2
0 EIA-485 (terminal)
1 EIA-232 (DSUB)
2 EIA-232 (terminal)
15 (20)
Comment
Read only
Read only
Read only
Read only
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Can be cleared
Default: 502
Default
Default: 60 seconds
Default
Default
Default: 1 stop bit
Default: 1000 ms
Default
HMSI-168-77 3.0
