Supercircuits SYRF04 System

Web Demo Quick Guide

You can access a Supercircuits model SYRF04 system, or DMR80U, DMR81U, or DMR82U DVR (and others)
with the Microsoft
Internet Explorer
(IE) browser. Before you can connect to it, however, you may need to
®
®
modify the security settings in your browser to load an ActiveX control.
To access a demo system, do the following:
1. At your Microsoft Windows
PC, open IE.
®
2. Open the IE Tools pull-down menu and
select Internet Options.
3. Click the Security tab.
4. Click the Custom Level... button. In the
Settings list.
5. In the list of Settings, change the following from Disable to Prompt:
Download unsigned ActiveX controls
Initialize and script ActiveX controls not marked as safe for scripting
1
www.supercircuits.com
6. Click OK, then click YES in the Warning window.
7. In the Internet Options window, click Apply, then click OK to close the window.
8. In the Internet Options window, click Apply, then click OK to close the window.
If your computer operating system is Windows Vista or Windows 7, User Account Control can
NOTE
interfere with the normal operation of the DVR user interface. To disable UAC, open the Control
Panel > User Account > User Account window, clear the Use User Account Control (UAC) to
help protect your computer check box, then click OK. A computer restart may be required.
9. In the IE URL field, enter the IP address assigned to your DVR. For the Web Demo system, enter:
70.132.198.196
Continue ➥
SYRF04_WebDemo_Q

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SYRF04 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Super Circuits SYRF04

  • Page 1 Supercircuits SYRF04 System 6. Click OK, then click YES in the Warning window. Web Demo Quick Guide 7. In the Internet Options window, click Apply, then click OK to close the window. You can access a Supercircuits model SYRF04 system, or DMR80U, DMR81U, or DMR82U DVR (and others) with the Microsoft Internet Explorer (IE) browser. Before you can connect to it, however, you may need to ® ® modify the security settings in your browser to load an ActiveX control. To access a demo system, do the following: 1. At your Microsoft Windows PC, open IE. ® 2. Open the IE Tools pull-down menu and select Internet Options. 3. Click the Security tab. 4. Click the Custom Level... button. In the Settings list. 8. In the Internet Options window, click Apply, then click OK to close the window. If your computer operating system is Windows Vista or Windows 7, User Account Control can NOTE interfere with the normal operation of the DVR user interface.
  • Page 2 If a message appears to load an ActiveX control, right-click on the message, then click Run Add-on in 11. After login, the DVR web display will appear. To see images from the cameras connected to your DVR, click the popup window. Follow the prompts to Install the program, even if a warning message appears that the the Open All button in the lower left corner of the screen. publisher cannot be verified. Logout 10. When the Login screen opens in the browser, enter the User Name and Pass Word, then click Login. For the Web Demo system, he User Name is “demo”, and Pass Word is “1111”. Click Login. (Do not change the Command Port entry (5050)). Open When viewing the DVR network browser interface, if the webpage appears normal but the camera images are scrambled, check your computer’s video adapter settings, or call Supercircuits Support at NOTE 1.800.335.9777 for assistance.
