- Page 1 Network Dome Camera Quick Start Guide...
- Page 2 Network Dome Camera·Quick Start Guide Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. About This Document This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual.
-
Page 3: Regulatory Information
Network Dome Camera·Quick Start Guide Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 4 Network Dome Camera·Quick Start Guide 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
-
Page 5: Safety Instruction
Network Dome Camera·Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected. - Page 6 Network Dome Camera·Quick Start Guide ● Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard. ● Please make sure that the plug is firmly connected to the power socket. When the product is mounted on wall or ceiling, the device shall be firmly fixed.
- Page 7 Network Dome Camera·Quick Start Guide ● Do not place the camera in extremely hot, cold (the operating temperature shall be-30°C ~+60°C, or -40°C ~ 60°C if the camera model has an “H” in its suffix), dusty or damp locations, and do not expose it to high electromagnetic radiation.
-
Page 8: Table Of Contents
Network Dome Camera·Quick Start Guide Table of Contents 1 Appearance Description ..............8 2 Installation ..................11 2.1 Ceiling Mounting ............12 2.2 Micro SD Card Installation ..........16 3 Setting the Network Camera over the LAN ........18 4 Accessing via Web Browser ............23... -
Page 9: Appearance Description
Network Dome Camera·Quick Start Guide 1 Appearance Description There are two types of camera appearance for this series of camera according to the different models. Figure 1-1 Overview of Type I Camera... - Page 10 Network Dome Camera·Quick Start Guide Figure 1-2 Overview Of Type II Camera Table 1-1 Description of Type I/II Camera Description Mounting Base Horizontal Stand Vertical Stand Bubble Network Interface Power Interface...
- Page 11 Network Dome Camera·Quick Start Guide Description IR LED Lens Black Liner Safety Rope Audio Interface (Only supported by the camera with “-A” in its model) Alarm Interface (Only supported by the camera with “-A” in its model) Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.
-
Page 12: Installation
Network Dome Camera·Quick Start Guide 2 Installation Before you start: Make sure the device in the package is in good condition and all the assembly parts are included. Make sure all the related equipment is power-off during the installation. -
Page 13: Ceiling Mounting
Network Dome Camera·Quick Start Guide ● Make sure that there is no reflective surface too close to the camera lens. The IR light from the camera may reflect back into the lens causing reflection. ● The foam ring around the lens must be seated flush against the inner surface of the bubble to isolate the lens from the IR LEDS. - Page 14 Network Dome Camera·Quick Start Guide Figure 2-2 Remove the Bubble 3. Fix the mounting base on the ceiling with screws. Figure 2-3 Fix the Mounting Base...
- Page 15 Network Dome Camera·Quick Start Guide If required, you can route cables through the side opening on the side of the mounting base. Side Opening Figure 2-4 Side Opening 4. Loosen the tilt lock screws, adjust the tilting position in a range of 65 degrees, and tighten the tilt lock screws.
- Page 16 Network Dome Camera·Quick Start Guide Type II camera supports 3-axis adjustment. Loosen the tilt adjust screw to adjust the tilt angle [0°~75°], hold the black liner to adjust the pan angle [0°~355°], and hold the lens to rotate the camera [0°~355°].
-
Page 17: Micro Sd Card Installation
Network Dome Camera·Quick Start Guide Micro SD Card Installation Steps: 1. Loosen the lock screws on the bubble to disassemble the camera. Figure 2-8 Disassemble the Camera 2. Insert the micro SD card to the card slot. 3. (Optional) Push the inserted micro SD card inside, and the micro SD card will be sprung out. - Page 18 Network Dome Camera·Quick Start Guide Figure 2-9 Insert the Micro SD Card 4. Install the bubble back, and tighten the lock screws on it. Figure 2-10 Install the Bubble...
-
Page 19: Setting The Network Camera Over The Lan
Network Dome Camera·Quick Start Guide 3 Setting the Network Camera over the Purpose: To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your PC. Then, install the SADP or client software to search and change the IP of network camera. - Page 20 Network Dome Camera·Quick Start Guide Use client software and to list the online devices. Please refer to the user manual of client software for detailed information. 2. Change the IP address and subnet mask to the same subnet as of your PC.
- Page 21 Network Dome Camera·Quick Start Guide Figure 3-2 Search Online Devices Device can be searched and displayed in the list in 15 seconds after it goes online; it will be removed from the list in 45 seconds after it goes offline. Search online devices manually: You can also click to refresh the online device list...
- Page 22 Network Dome Camera·Quick Start Guide You can click on each column heading to order the information; you can click to show the device table and hide the network parameter panel on the right side, or click to show the network parameter panel. ...
- Page 23 Network Dome Camera·Quick Start Guide Figure 3-4 Modify Network Parameters 3. Enter the IP address of network camera in the address field of the web browser to view the live video. The default value of the IP address is “192.0.0.64”. The default user name is “admin”, and password is “12345”.
-
Page 24: Accessing Via Web Browser
Network Dome Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz to Core i7-4000 series or higher, depending on different video resolutions RAM: 1G or higher Display: 1024×768 resolution or higher... - Page 25 Network Dome Camera·Quick Start Guide Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. You may have to close the web browser to finish the installation of the plug-in.
- Page 26 Network Dome Camera·Quick Start Guide Figure 4-2 Download Plug-in Figure 4-3 Install Plug-in (1)
- Page 27 Network Dome Camera·Quick Start Guide Figure 4-4 Install Plug-in (2) 6. Reopen the web browser after the installation of the plug-in and repeat steps 2-4 to login. For detailed instructions of further configuration, please refer to the user manual of network camera.
