PB 8224
Wood Roof Kit
check out http://www.swing-n-slide.com/planupdates.html
for updates to these instructions
For more information, visit this link:
http://www.swing-n-slide.com
ASSEMBLY INSTRUCTIONS
Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545
Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232
Advertisement
Related Manuals for Swing-N-Slide Rapid Loc PB 8224
Summary of Contents for Swing-N-Slide Rapid Loc PB 8224
- Page 1 Wood Roof Kit check out http://www.swing-n-slide.com/planupdates.html for updates to these instructions For more information, visit this link: http://www.swing-n-slide.com ASSEMBLY INSTRUCTIONS Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545 Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232...
- Page 2 When the equipment is taken out of service, it must be disassembled and disposed of in such a way that no unreasonable hazards will exist at the time the set is discarded. Important! Additional Safety Instructions for all Swing-N-Slide Playground Equipment. Save this instruction sheet in the event the manufacturer needs to be contacted.
- Page 3 Wood Roof Assembly Instructions TOOLS REQUIRED ELECTRIC DRILL SAFETY GLASSES CARPENTER'S SQUARE TAPE MEASURE & DUST MASK (62) 1-1/2'' screws (12) 2-1/2'' screws (36) 1-1/4'' screws (1) T20 Torx® Bit Wood Roof Plan (2) Roof Support (1) Plan Plate...
- Page 4 Wood Roof Assembly Instructions Wood Roof Board List (2) 2'' x 4'' x 35'' (2) 2'' x 4'' x 38-1/2'' (16) 1'' x 5-1/4'' x 47-1/2'' Roof Slats (2) 1'' x 4'' x 38-1/2''...
- Page 5 Wood Roof Assembly Instructions BROOKVIEW WOOD ROOF APPLICATION Fig. 1 Fig. 1a A. Remove Tarp and Frame: 1. Remove Tarp from your unit and detach the Tarp support frame as shown in (Fig. 1) and (Fig 1a).
- Page 6 Wood Roof Assembly Instructions BROOKVIEW WOOD ROOF APPLICATION Fig. 2 Fig. 2a 1-1/4'' deck screws per plate 1-1/2'' deck screws per joint Note: Use Ribs In Plate To Align 2'' x 4''s Fig. 2b B. Assemble Roof Frame: 2-1/2'' screws Make Top Surface of 2'' x 4'' per joint A-Frames Flush With Top...
- Page 7 Wood Roof Assembly Instructions BROOKVIEW WOOD ROOF APPLICATION Fig. 3 1-1/2'' deck screws per joint Fig. 3b Fig. 3a 1-1/4'' deck screws per board. Note: Place screws so they go through the thickest area of the roof slat board. C. Finish Roof: 1.
- Page 8 Wood Roof Assembly Instructions PALISADE WOOD ROOF APPLICATION Fig. 1 Fig. 1a (2) 5/4'' x 4'' x 47-1/2'' A. Remove Tarp and Frame: 1. Remove Pleated Tarp from your unit as shown in (Fig 1). 2. Remove the support boards as shown in (Fig.
- Page 9 Wood Roof Assembly Instructions PALISADE WOOD ROOF APPLICATION Fig. 2 2-1/2'' screws per joint NOTE: Roof 1 and 2 are built differently. See (Fig. 4) Through (Fig. 5) on pages 11 through 12 for Roof 2 Assembly. Fig. 2a B. Reattach Boards, Build A-Frames: 1.
- Page 10 Wood Roof Assembly Instructions PALISADE WOOD ROOF APPLICATION ROOF 1 ASSEMBLY Fig. 3 Make Top Surface of 2'' x 4'' A-Frames Flush With Top Edge of 4'' x 4'' uprights. 2-1/2'' screws per joint 16-1/2'' 16-1/2'' Fig. 3a 1-1/2'' deck screws C.
- Page 11 Wood Roof Assembly Instructions PALISADE WOOD ROOF APPLICATION ROOF 2 ASSEMBLY Fig. 4 1-1/2'' deck screws per joint FLUSH Fig. 4a D. Build Roof Frame and Attach: Make Top Surface of 2'' x 4'' A-Frames Flush With Top Edge of 4'' x 4'' uprights. 1.
- Page 12 Wood Roof Assembly Instructions PALISADE WOOD ROOF APPLICATION ROOF 2 ASSEMBLY Fig. 5 1-1/2'' deck screws per joint Fig. 5b 1-1/4'' deck screws Fig. 5a per board. Note: Place screws so they go through the thickest area of the roof slat board. E.
- Page 13 Wood Roof Assembly Instructions PALISADE WOOD ROOF APPLICATION Fig. 6 1-1/2'' screws per joint F. Spacer Board: 1. Attach (1) 5/4'' x 4'' x 40'' (from pg. 8 - (Fig. 1a)) to unit as shown in (Fig. 6). 1-1/2'' screw...
- Page 14 Wood Roof Assembly Instructions...
- Page 15 Wood Roof Assembly Instructions...
- Page 16 Questions???... Call our Customer Service Department at 1-800-888-1232 © PlayCore Inc. 2008 Printed In USA LA 5910...
